73
DEC address
Variable
name
Description / Variables Settings Menu States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
179 358 mWorkFX Minimum operating time of the reversing freon unit 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
180 360 Tout_min Minimum outside temperature above which the freon cooler can operate 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
181 362 negAFX Negation of the alarm contact of the reversible freon unit 0 - NO, 1 - NC MSV
Coil 5792
R/W
182 364 DefFunc System response to defrost signal 0 - System stop, 1 - Low gear, 2 - No reaction MSV Register R/W
183 366 A_M_Mix Mixing chamber operation mode 0 - manual, 1 - auto MSV
Coil 5856
R/W
184 368 SetMix Mixing chamber setting in manual mode 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
185 370 PrioMH Priotity in temperature control for 0 - mixing chamber, 1 - heater/cooler MSV
Coil 5920
R/W
186 372 MinFresh Minimum fresh air 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
187 374 MaxFresh Maximum fresh air 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
188 376 TlimMCH Temperature setting for fast heating mode with mixing chamber 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
189 378 HistMCH
Setting of the setpoint temperature hysteresis for fast heating mode with
the mixing chamber
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
Table no. 17 Variables Service menu
DEC address
Variable
name
Description / Variables Service Menu States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
190 380 ServiceMode Service mode 0 - inactive, 1 - active MSV
Coil 6080
R/W
191 382
Ch_Work
Mode
Operating modes: select 1 of 4 operating mode settings
1 - o/on, 2 - o,1,2,3, 4 - o,1,2,3,Timer,
8 - o,1,2,3,Standby,Timer
MSV Register R/W
192 384 Type Setting the application code 1 - SCS, 2 - SECS, 10 - PRCS, 18 - RRCS MSV Register R/W
193 386 AplCode Setting the application code 1 = 1 (22 = 22) AV Register R/W
194 388 CodeOK
Information about the compatibility of the inserted application code with
the available codes described in the OMM
0 - incorrect, 1 - correct MSV
Coil 6208
R
195 390 OfsPT1
Correction of the measurement point of the temperature sensor connected
to input PT1
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
196 392 OfsPT2
Correction of the measurement point of the temperature sensor connected
to input PT2
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
197 394 OfsPT3
Correction of the measurement point of the temperature sensor connected
to input PT3
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
198 396 OfsPT4
Correction of the measurement point of the temperature sensor connected
to input PT4
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
199 398 OfsPT5
Correction of the measurement point of the temperature sensor connected
to input PT5
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
200 400 OfsHMICon
Correction of the measurement point of the temperature sensor connected
to the HMI CON connector
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
201 402 OfsHMIRS
Correction of the measure-ment point of the tempera-ture sensor connec-
ted to the MASTER RS485 connector
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
202 404
LowTemp
Act
Low supply temperature alarm A_LowTemp 0 - inactive, 1 - active MSV
Coil 6464
R/W
203 406 TminSup Minimum permitted supply temperature 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
204 408 DelTemp Alarm delay for low supply temperature A_LowTemp 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
205 410 TexhAct Exhaust temperature sensor 0 - inactive, 1 - active MSV
Coil 6560
R/W
206 412 TsetChT
Set temperature set point change ramp (applies to Tset change from menu
or calendar)
1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
207 414
AirReg-
Sensor
Air quality sensor
0 - inactive, 1 - CO2, 2 - LZO,
4 - PM2.5, 8 - PM10
MSV
Coil 6624
R/W
