74
AUTOMATION AND CONTROLLER FOR UNITS EVO-T; EVO-T COMPACT
OPERATION AND MAINTENANCE MANUAL
DEC address
Variable
name
Description / Variables Service Menu States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
208 416 AirRegMix Activation of the air quality control function with the mixing chamber 0 - inactive, 1 - active MSV
Coil 6656
R/W
209 418 AirRegVent Activation of the air quality control function with air fans 0 - inactive, 1 - active MSV
Coil 6688
R/W
210 420 PrioAirReg Priotity in air quality regulation for 0 - mixing chamber, 1 - fans MSV
Coil 6720
R/W
211 422 Kp_Air Increase of the air quality control system 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
212 424 Ti_Air Integration constant of the air quality control system 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
213 426
LimPidA-
irReg
Limit of air quality control level 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
214 428 SetCO2 CO2 setting 1ppm =256(22ppm=22*256= 5632 = 0x1600) AV Register R/W
215 430 SetLZO volatile organic compound setting 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
216 432 SetPM2_5 PM2.5 concentration setting 1µg/m3=256(22µg/m3=22*256=5632=0x1600) AV Register R/W
217 434 SetPM10 PM10 concentration setting 1µg/m3=256(22µg/m3=22*256=5632=0x1600) AV Register R/W
218 436 SupPMlim Minimum capacity of the supply air fan (for PM controller) 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
219 438 ExhPMlim Minimum capacity of the exhaust fan (for PM controller) 1% = 256 (22% = 22*256 = 5632 = 0x1600) AV Register R/W
220 440 UminAirReg Lower voltage threshold of the air quality sensor 1V = 256 (22 = 22*256 = 5632 = 0x1600) MSV Register R/W
221 442 UmaxAirReg Upper voltage threshold of the air quality sensor 1V = 256 (22 = 22*256 = 5632 = 0x1600) MSV Register R/W
222 444 ppmMin CO2 value setting for 0V signal 1ppm = 256 (22 ppm =22*256=5632=0x1600) MSV Register R/W
223 446 ppmMax CO2 value setting for 10V signal 1ppm = 256 (22 ppm =22*256=5632=0x1600) MSV Register R/W
224 448 LZOmin LZO value setting for 0V signal 1% = 256 (22 = 22*256 = 5632 = 0x1600) MSV Register R/W
225 450 LZOmax LZO value setting for 10V signal 1% = 256 (22 = 22*256 = 5632 = 0x1600) MSV Register R/W
226 452 PM2_5min PM2.5 value setting for 0V signal 1µg/m3=256(22µg/m3=22*256=5632=0x1600) MSV Register R/W
227 454 PM2_5max PM2.5 value setting for 10V signal 1µg/m3=256(22µg/m3=22*256=5632=0x1600) MSV Register R/W
228 456 PM10min PM10 value setting for 0V signal 1µg/m3=256(22µg/m3=22*256=5632=0x1600) MSV Register R/W
229 458 PM10max PM10 value setting for 10V signal 1µg/m3=256(22µg/m3=22*256=5632=0x1600) MSV Register R/W
230 460 ConstPress Activation of constant duct pressure control or constant fan output control 0 - Inactive, 1 - pressure, 2 - pressure/airow MSV Register R/W
231 462 FanInverters Selection of fan control type 1 - Danfoss FC51, 2 - EBM MSV Register R/W
232 464
ActualAdrE-
BM
EBM current address 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
233 466
AdrToSet
EBM
EBM Target address 1 = 256 (22 = 22*256 = 5632 = 0x1600) AV Register R/W
234 468
ActiveCon-
g EBM
Activation of EBM new address setting 0 - No, 1 - Yes MSV
Coil 7488
R/W
235 470
StatusConf
EBM
Communication / loading status of the EBM motor settings
0 - ok (correct communication), 1 - In progress
(loading settings), 2 - alarm (communication)
MSV Register R/W
236 472 Sup0_10 0-10VDC control of the supply inverter
0 - inactive, 1 - Aout1, 2 - Aout2,
4 - Aout3, 8 - Aout4
MSV Register R/W
237 474 Exh0_10 0-10VDC control of the exhaust inverter
0 - inactive, 1 - Aout1, 2 - Aout2,
4 - Aout3, 8 - Aout4
MSV Register R/W
238 476 RecMode Recovery operation mode 1 - heat recovery, 3 - heat and cold recovery MSV Register R/W
239 478 RecFrostProt Selection of the recovery frost protection 0 - pressure switch, 1 - temperature sensor MSV
Coil 7648
R/W
240 480 FrostAlarm Frost recovery alarm A_ColdRec 0 - inactive, 1 - active MSV
Coil 7680
R/W
241 482 MixMode Recovery operation mode 1 - heat recovery, 3 - heat and cold recovery MSV Register R/W
242 484 HCwaterAct Water heat exchanger heater / cooler 0 - inactive, 1 - active MSV
Coil 7744
R/W
243 486 HEcontrol Type of electric heater control (output Aout1) 0 - 0-100%, 1 - PWM MSV
Coil 7776
R/W
