AUTOMATION AND CONTROLLER FOR UNITS EVO-T; EVO-T COMPACT
OPERATION AND MAINTENANCE MANUAL
DEC address
Variable
name
Description / Variables Service Menu States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
279 558 T6 Leading temperature history - measurement 6 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
280 560 T7 Leading temperature history - measurement 7 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
281 562 T8 Leading temperature history - measurement 8 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
282 564 T9 Leading temperature history - measurement 9 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
283 566 T10 Leading temperature history - measurement 10 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
284 568 T11 Leading temperature history - measurement 11 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
285 570 T12 Leading temperature history - measurement 12 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
286 572 T13 Leading temperature history - measurement 13 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
287 574 T14 Leading temperature history - measurement 14 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
288 576 T15 Leading temperature history - measurement 15 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
289 578 HistPeriod Temperature measurement period 1s = 256 (22s = 22*256 = 5632 = 0x1600) AV Register R/W
290 580 Reset Reset of measurements from the leading temperature history 0 - o 1 - on MSV
Coil 9280
R/W
291 582 _DIN1 Digital input status reading 1 0 - open, 1 - shorted MSV
Coil 9312
R
292 584 _DIN2 Digital input status reading 2 0 - open, 1 - shorted MSV
Coil 9344
R
293 586 _DIN3 Digital input status reading 3 0 - open, 1 - shorted MSV
Coil 9376
R
294 588 _DIN4 Digital input status reading 4 0 - open, 1 - shorted MSV
Coil 9408
R
295 590 _DIN5 Digital input status reading 5 0 - open, 1 - shorted MSV
Coil 9440
R
296 592 _DIN6 Digital input status reading 6 0 - open, 1 - shorted MSV
Coil 9472
R
297 594 _DIN7 Digital input status reading 7 0 - open, 1 - shorted MSV
Coil 9504
R
298 596 _DIN8 Digital input status reading 8 0 - open, 1 - shorted MSV
Coil 9536
R
299 598 _DIN9 Digital input status reading 9 0 - open, 1 - shorted MSV
Coil 9568
R
300 600 _DIN10 Digital input status reading 10 0 - open, 1 - shorted MSV
Coil 9600
R
301 602 _DIN11 Digital input status reading 11 0 - open, 1 - shorted MSV
Coil 9632
R
302 604 _DIN12 Digital input status reading 12 0 - open, 1 - shorted MSV
Coil 9664
R
303 606 Ain_1 Analogue input status reading 1 1V = 256 (22V = 22*256 = 5632 = 0x1600) AV Register R
304 608 Ain_2 Analogue input status reading 2 1V = 256 (22V = 22*256 = 5632 = 0x1600) AV Register R
305 610 Ain_3 Analogue input status reading 3 1V = 256 (22V = 22*256 = 5632 = 0x1600) AV Register R
306 612 PT_1 PT1000 Sensor input reading 1 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
307 614 PT_2 PT1000 Sensor input reading 2 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
308 616 PT_3 PT1000 Sensor input reading 3 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
309 618 PT_4 PT1000 Sensor input reading 4 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
310 620 PT_5 PT1000 Sensor input reading 5 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
311 622 HMI_Con Sensor reading in the HMI controller connected via HMI CON 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
312 624 HMI_RS Sensor reading in the HMI controller connected via RS485 Master 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R
313 626 Re1 Digital output status reading 1 0 - o, 1 - on MSV
Coil 10016
R
314 628 Re2 Digital output status reading 2 0 - o, 1 - on MSV
Coil 10048
R
315 630
Re3
Digital output status reading 3 0 - o, 1 - on MSV
Coil 10080
R
316 632 Re4 Digital output status reading 4 0 - o, 1 - on MSV
Coil 10112
R
317 634 Re5 Digital output status reading 5 0 - o, 1 - on MSV
Coil 10144
R
318 636 Re6 Digital output status reading 6 0 - o, 1 - on MSV
Coil 10176
R
319 638 Re7 Digital output status reading 7 0 - o, 1 - on MSV
Coil 10208
R
