77
DEC address
Variable
name
Description / Variables Service Menu States
Type Read [R]
/Write
[W]
BacNet Modbus BacNet Modbus
320 640 Re8 Digital output status reading 8 0 - o, 1 - on MSV
Coil 10240
R
321 642 AO1 Analogue output status reading 1 1V = 256 (22V = 22*256 = 5632 = 0x1600) AV Register R
322 644 AO2 Analogue output status reading 2 1V = 256 (22V = 22*256 = 5632 = 0x1600) AV Register R
323 646 AO3 Analogue output status reading 3 1V = 256 (22V = 22*256 = 5632 = 0x1600) AV Register R
324 648 AO4 Analogue output status reading 4 1V = 256 (22V = 22*256 = 5632 = 0x1600) AV Register R
325 650 F_DIN1 Digital input emulation 1 0 - no emulation, 1 - set open, 3 - set shorted MSV Register R/W
326 652 F_DIN2 Digital input emulation 2 0 - no emulation, 1 - set open, 3 - set shorted MSV Register R/W
327 654 F_DIN3 Digital input emulation 3 0 - no emulation, 1 - set open, 3 - set shorted MSV Register R/W
328 656 F_DIN4 Digital input emulation 4 0 - no emulation, 1 - set open, 3 - set shorted MSV Register R/W
329 658 F_DIN5 Digital input emulation 5 0 - no emulation, 1 - set open, 3 - set shorted MSV Register R/W
330 660 F_DIN6 Digital input emulation 6 0 - no emulation, 1 - set open, 3 - set shorted MSV Register R/W
331 662 F_DIN7 Digital input emulation 7 0 - no emulation, 1 - set open, 3 - set shorted MSV Register R/W
332 664 F_DIN8 Digital input emulation 8 0 - no emulation, 1 - set open, 3 - set shorted MSV Register R/W
333 666 F_DIN9 Digital input emulation 9 0 - no emulation, 1 - set open, 3 - set shorted MSV Register R/W
334 668 F_DIN10 Digital input emulation 10 0 - no emulation, 1 - set open, 3 - set shorted MSV Register R/W
335 670 F_DIN11 Digital input emulation 11 0 - no emulation, 1 - set open, 3 - set shorted MSV Register R/W
336 672 F_DIN12 Digital input emulation 12 0 - no emulation, 1 - set open, 3 - set shorted MSV Register R/W
337 674 Em_Ai1 Analogue input emulation 1 0 - inactive, 1 - active MSV
Coil 10784
R/W
338 676 E_Ai1 Analogue input emulated value 1 1V = 256 (10V = 10*256 = 2560 = 0xA00) AV Register R/W
339 678 Em_Ai2 Analogue input emulation 2 0 - inactive, 1 - active MSV
Coil 10848
R/W
340 680 E_Ai2 Analogue input emulated value 2 1V = 256 (10V = 10*256 = 2560 = 0xA00) AV Register R/W
341 682 Em_Ai3 Analogue input emulation 3 0 - inactive, 1 - active MSV
Coil 10912
R/W
342 684 E_Ai3 Analogue input emulated value 3 1V = 256 (10V = 10*256 = 2560 = 0xA00) AV Register R/W
343 686 Em_PT1 PT1000 Sensor input emulation 1 0 - inactive, 1 - active MSV
Coil 10976
R/W
344 688 E_PT1 PT1000 Sensor input emulated value 1 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
345 690 Em_PT2 PT1000 Sensor input emulation 2 0 - inactive, 1 - active MSV
Coil 11040
R/W
346 692 E_PT2 PT1000 Sensor input emulated value 2 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
347 694 Em_PT3 PT1000 Sensor input emulation 3 0 - inactive, 1 - active MSV
Coil 11104
R/W
348 696 E_PT3 PT1000 Sensor input emulated value 3 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
349 698 Em_PT4 PT1000 Sensor input emulation 4 0 - inactive, 1 - active MSV
Coil 11168
R/W
350 700 E_PT4 PT1000 Sensor input emulated value 4 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
351 702 Em_PT5 PT1000 Sensor input emulation 5 0 - inactive, 1 - active MSV
Coil 11232
R/W
352 704 E_PT5 PT1000 Sensor input emulated value 5 1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
353 706 Em_Hcon
Emulation of the sensor input in the controller connected to the HMI CON
connector
0 - inactive, 1 - active MSV
Coil 11296
R/W
354 708 E_Hcon
Emulated value of the sensor in the controller connected to the HMI CON
connector
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
355 710 Em_Hrs
Emulation of the sensor input in the controller connected to the RS485
connector
0 - inactive, 1 - active MSV
Coil 11360
R/W
356 712 E_Hrs
Emulated value of the sensor in the controller connected to the RS485
connector
1°C = 256 (22 °C = 22*256 = 5632 = 0x1600) AV Register R/W
357 714 F_Re1 Digital output forcing 1 0 - no forcing, 1 - forcing o, 3 - forcing on MSV Register R/W
