Kodak 8000C Installation Guide

General Overview
KODAK 8000C Digital Panoramic and Cephalometric Extraoral Imaging System Installation Guide (SM736)_Ed 02 2–3
General Functional Components
Figure 2-2 illustrates the general functional components of the KODAK 8000C digital
panoramic and cephalometric units.
Figure 2–2 KODAK 8000 and KODAK 8000C Units Functional Components
1 Height adjustment buttons 14 X-Ray source assembly
2 Control panel 15 Unit rotative arm
3 Hand Grip 16 Panoramic sensor
3a Temple supports control knob 17 Component to raise for Cephalometric mode
4 Chin rest base 18 ON/OFF button
4a Chin rest and bite block 19 Wall mounting brackets cover
5 Temple supports 20 Wall mounting brackets
6 Unit mains connecting terminal 21 Column upper cover
7 Green warning lamp (ready state indicator) 22 Panoramic head cover
8 Column connecting terminal 23 Cephalostat arm
RJ45/2
24
25
23
26
19
21
22
29
28
27
8
RJ45/1
20
16
17
11
10
6
7
13
12
9
3
2
5
4a
4
14
15
18
3a
1
