Post-Installation Control
KODAK 8000C Digital Panoramic and Cephalometric Extraoral Imaging System Installation Guide (SM736)_Ed 02 5–15
5. If needed, adjust the cephalostat head mechanically:
• For a vertical adjustment, use the cephalostat arm screws (A).
• For a horizontal adjustment, use the elbow tube clamps screws (B).
Adjusting the Nasion Support
To adjust the nasion support, follow these steps:
1. Lower the nasion support to a vertical position.
2. Access the Cephalometric Acquisition Window. In the Program pane, click .
3. Launch an x-ray using the x-ray remote control. The nasion support must be
perpendicular to the ear cones.
4 mm
B
B
A
