Post-Installation Control
5–12 INSTALLING THE CEPHALOSTAT
Adjusting the Height of the Cephalostat Head
To adjust the height of the cephalostat head, follow these steps:
1. Position the head clamps in a lateral position.
2. Access the Cephalometric Acquisition Window. In the Program pane, click .
3. Launch an x-ray using the x-ray remote control.
4. In the Imaging Window, on the drawing toolbar, click . On the acquired image,
draw a line from the bottom of the image to the center of the ball (ear cone). The
resulting value must be:
• Height: 30mm (
± 5mm)
• Length: 110mm (
± 5mm)
110 mm (± 5 mm)
30 mm (± 5 mm)
