Post-Installation Control
KODAK 8000C Digital Panoramic and Cephalometric Extraoral Imaging System Installation Guide (SM736)_Ed 02 5–11
4. If needed, adjust the cephalostat head mechanically using the elbow tube for
horizontal inclination of the cepahlostat head. Untighten the fixing screws (A) slightly.
Use the fixing screws (B) to adjust the horizontal inclination. Tighten the fixing screws
(A) when you have reached the desired adjustment.
2.5 mm
A
x4
x1
x1
B
B
4 mm
A
