Post-Installation Control
5–16 INSTALLING THE CEPHALOSTAT
4. In the Imaging Window, on the drawing toolbar, click . On the acquired image,
draw a perpendicular line between the center of the ear cones and the nasion support
holes to check that the nasion support is positioned vertically. The resulting value
must be A = B
±3mm.
5. If needed, adjust the nasion support, using the nasion support fixing screws (A).
3 mm
A
B
2 mm
A
