Kodak 8000C Installation Guide

Electrical Requirements
KODAK 8000C Digital Panoramic and Cephalometric Extraoral Imaging System Installation Guide (SM736)_Ed 02 4–5
A single-phase alternating current power supply is required.
The electrical installation specifications should be as follows:
Table 4–2 Electrical Installation Specifications
Supply Voltage
230V/240V
100V/110V
/ 130V
Frequency 50/60 Hz 50/60 Hz
Electrical supply 6 kW 6 kW
Line current
required
16A 20A
Cable cross-section
according to length
For 30 m:
2.5 mm2
For 10 m:
2.5 mm2
Max. line
impedance
0.5 0.12
Differential circuit
breaker (2)
30 mA 30 mA
Maximum current to
trip circuit breaker
16A 20A Protect the power supply line with a
differential circuit breaker that trips at
maximum current.
Specifications of 2
red color actuator
emergency stop
push-button
(3) and (4)
250V 6A
UL listed
250V 6A
UL listed
• Install these stop push-buttons to
simultaneously, switch off the
current to the active conductors
of the radiological installation and
exclude any other electric
equipment.
• Locate (3) inside the x-ray room,
near the unit, for the operator to
quickly cut the power supply if
necessary.
• Locate (4) outside the x-ray room,
near the x-ray remote control for
the operator to quickly cut the
power supply if necessary.
• Maintain them in OFF (open)
position until a deliberate action
is performed.
