Chapter 7 MDC-1840BB/1841BB/1860BB/1810BB/1820BB Series
Graphic Displays Operation Manual
7-8 93142122-07
Table 7.5 MARKS USED IN THE MAP
No. Mark shape Applicable objects
0
Light
1
Lighthouse, Aeronautical
light, Light beacon, etc.
2
Buoy
3
Large mooring buoy
4
Radio and/or radar station
5
Dry rock
6
Awash rock
7
Reef, submerged rock, etc.
8
Surface object, wreck,
Hazardous point, etc
9
Rush tidal current, eddy,
etc.
