MDC-1840BB/1841BB/1860BB/1810BB/1820BB Series Chapter 3
Operation Manual Technical Specifications
0093142122-08 3-7
[Antenna unit]
Figure 3.3 External dimensions of the Antenna unit, RB717A / RB718A
