Field Service Ver. 1.0 Dec. 2008 10. Tech. Rep. Mode
177
bizhub 362/282/222
ADJUSTMENT/
SETTING
10.8.3 I/O Check List
A. Printer (Main Body, PC-108, PC-206, PC-407)
Symbol Panel Display Part/Signal Name
Operation Characteris-
tics/ Panel Display
10
PC1
Bypass/Duplex
Timing Roller Synchronizing Roller Sensor
Paper
present
Paper not
present
PC4 Exit Paper Exit Sensor
Paper
present
Paper not
present
PC2 2nd Paper Feed Vertical Conveyance Sensor
Paper
present
Paper not
present
PC117-PF 3rd Paper Feed Tray3 Vertical Conveyance Sensor
Paper
present
Paper not
present
PC126-PF 4th Paper Feed Tray4 Vertical Conveyance Sensor
Paper
present
Paper not
present
- Bypass Tray Manual Bypass Tray Set signal Not set Set
PC18 Paper Empty Bypass Paper Empty Sensor
Paper not
present
Paper
present
PC19 FD Size 1 Bypass FD Paper Size Sensor/1
Paper
present
Paper not
present
PC20 FD Size 2 Bypass FD Paper Size Sensor/2
Paper
present
Paper not
present
PC21 FD Size 3 Bypass FD Paper Size Sensor/3
Paper
present
Paper not
present
PC22 FD Size 4 Bypass FD Paper Size Sensor/4
Paper
present
Paper not
present
PC29
Bypass Tray Pick
Up
Bypass Lift Sensor Unblocked Blocked
PC24
Duplex Paper
Passage 1
Duplex Unit Upper Transport Sensor
Paper
present
Paper not
present
PC25
Duplex Paper
Passage 2
Duplex Unit Lower Transport Sensor
Paper
present
Paper not
present
PC26 Reverse Switch Back Unit Sensor
Paper
present
Paper not
present
- Duplex Set Duplex Unit Set signal
Out of
position
Set
PC23 Duplex Cover Duplex Unit Door Sensor Open Close
VR1
Bypass Paper
Width Detect
Bypass Paper Size Detection Unit Analog value
To Next Page
