1. Product specifications Field Service Ver. 1.0 Dec. 2008
2
DF-620
OUTLINE
D. Paper feed prohibited originals
• If fed, trouble occurrence will be highly possible.
E. Paper feed not guaranteed originals
• If fed, paper feed will be possible to some extent but trouble occurrence will be possible.
Type of Original Possible Trouble
Original that is stapled or clipped.
Feed failure, damage to the original, or drive
failure due to clip clogging
Book original
Feed failure, damage to the original, or drive
failure
Original weighing less than 35g/m
2
or
129g/m
2
or more
Feed failure
Torn original Feed failure, damaged sheet
Highly curled original (15 mm or more) Original misfeed due to dog-ear or skew
OHP transparencies Feed failure
Label Sheet Feed failure
Offset master Feed failure
Sheets clipped or notched Damaged sheet
Sheets patched
Patched part folded or torn sheet, Sheets
misfed
Type of Original Possible Trouble
Sheets lightly curled (Curled amount: 10 - 15 mm) Dog-eared, exit failure
Heat Sensitive Paper Edge folded, exit failure, transport failure
Coated Paper (Ink Jet Paper) Take-up failure, transport failure
Translucent paper Take-up failure, transport failure
Paper immediately after paper exit from the main unit Take-up failure, transport failure
Paper with many punched holes (e.g., loose leaf) limited
to vertical feeding
Multi-page feed due to flashes from holes
Sheets with 2 to 4 holes Transport failure
Sheets two-folded or Z-folded Transport failure, image deformation
Sheets with rough surface (e.g., letterhead) Take-up failure
Sheets folded
Image deformation, multi-page feed, take-up
failure
To Next Page
