Easy Mode
The Style Play page in detail
Introduction
The Style Play page in detail
Notes:
• There are three Sounds for the right hand (Upper 1, Upper 2,
Upper 3), and only one Sound for the left hand (Lower). Their
names are abbreviated as UP1, UP2 UP3, LOW, and are shown
in the right side of the display.
• Right hand (Upper) and left hand (Lower) Sounds are sepa-
rated by the Split Point.
• Performances and STSs are collections of Sounds. Just choose
one of them to change all the Sounds of the keyboard (and,
when the STYLE CHANGE LED is lit on the control panel, of
the Style).
• Choose a Style to change the musical style of the accompani-
ment patterns. Touching the Style name in the display is the
same as to press one of the buttons of the STYLE section on the
control panel.
Sound icon and status. If
the icon appears,
the Sound is in mute and
cannot be heard. If the
icon does not appear, the
Sound is in play and can
be heard.
→
page 35
Sounds assigned to the right hand (UP1 to UP3)
and to the left hand (LOW). Touch the Sound’s
name to open the Sound Select window and
choose a different Sound.
→
page 76
Style name and info. Touch the Style’s name
to open the Style Select window and choose
a different Style.
→
page 77
Tempo. Use the
DIAL to change it.
Length of the accompaniment
pattern, and current beat.
Performance or STS. Touch it to
open the Performance Select win-
dow and choose a different Per-
formance. Sounds on the
keyboard will change.
→
page 76
Touch here to change the
Split Point.
→
page 38
Close this lock to avoid
transposition when
choosing a different
Performance or Style.
→
page 203
Single Touch Settings (STS). Touch one of them to choose it, or use the dedicated
buttons on the control panel. Sounds on the keyboard will change.
→
page 78
Touch it to adjust the tracks pan
and volume.
→
page 50
Touch it to choose and program
the effects.
→
page 91
