150
Song Play operating mode
Song Tracks 1-8 and 9-16 pages
You can also transpose all Upper tracks by using the UPPER
OCTAVE buttons on the control panel.
Keyboard track name
Non editable. Name of the corresponding track:
Sound bank’s icon
This picture illustrates the bank the current Sound belongs to.
Keyboard track status
Play/mute status of the current track. Press this icon to change
the status.
No icon Play status. The track can be heard.
Mute status. The track cannot be heard.
Panels
The lower half of the main page contains the various panels, you
can select by pressing the corresponding tabs. See more informa-
tion in the relevant sections, starting from page 151.
Song Tracks 1-8 and 9-16 pages
Repeatedly press the TRACK SELECT button to cycle between
the Normal, Song Tracks 1-8 and Song Tracks 9-16 view. In Song
Track views, the upper half of the main page changes, to show
parameters for the Song tracks.
Press TRACK SELECT again to return to Normal view (Key-
board tracks). (See “Main page” on page 148).
Songs area
Despite a different layout, it works as the Song area in the Nor-
mal view.
Selected Track Info area
This line lets you see the Sound assigned to the selected track.
Not only it is shown on the main page, but also in several edit
pages.
Track name
Name of the selected track.
Sound name
Sound assigned to the selected track. Press anywhere in this area
to open the Sound Select window, and select a different Sound.
Sound bank
Bank the selected Sound belongs to.
Abbreviation Track Hand
UP1 Upper 1 Right hand
UP2 Upper 2
UP3 Upper 3
LOW Lower Left hand
Volume panel
Tabs
Selected track
info area
Sounds area
Track name
Songs area
Track name
Sound name
Sound bank
Program Change
Pa500-110UM-ENG.book Page 150 Friday, March 28, 2008 11:12 AM
