Korg PA 500 User Manual

8
Easy Mode
The Song Play page in detail
The Song Play page in detail
Notes:
• As in Style mode, there are three Sounds for the right hand
(Upper 1, Upper 2, Upper 3), and only one Sound for the left
hand (Lower). Their names are abbreviated as UP1, UP2 UP3,
LOW, and are shown in the right side of the display.
• Right hand (Upper) and left hand (Lower) Sounds are sepa-
rated by the Split Point.
• Performances and STSs are collections of Sounds. Just choose
one of them to change all the Sounds of the keyboard.
• Available STSs depend on the Style you last selected.
• Since there are two onboard Sequencers, you can play two
Songs at the same time. Mix them using the SEQUENCER BAL-
ANCE slider on the control panel.
• Touching a Song name in the display is the same as to press one
of the SONG SELECT buttons on the control panel. Each
Sequencer has its own SONG SELECT and transport buttons.
Sound icon and status. If
the icon appears,
the Sound is in mute and
cannot be heard. If the
icon does not appear, the
Sound is in play and can
be heard.
→ page 35
Sounds assigned to the right hand (UP1 to UP3)
and to the left hand (LOW). Touch the Sound’s
name to open the Sound Select window and
choose a different Sound.
→ page 76
Song assigned to Sequencer 1. Touch it to
open the Song Select window and choose a
different Song.
→ page 78
Tempo. Use the
DIAL to change it.
Song assigned to Sequencer 2.
Touch it to open the Song Select
window and choose a different
Song.
→ page 78
Performance or STS. Touch it to
open the Performance Select win-
dow and choose a different Per-
formance. Sounds on the
keyboard will change.
→ page 76
Touch here to change the
Split Point.
→ page 38
Close this lock to avoid
transposition when
choosing a different
Performance or Style.
→ page 203
Touch it to adjust the tracks pan
and volume.
→ page 56
Touch it to choose and adjust the
effects.
→ page 158
Single Touch Settings (STS). Touch one of them to choose it, or use the dedicated
buttons on the control panel. Sounds on the keyboard will change.
→ page 78
Touch here to see the
Song’s Lyrics.
→ page 9
Pa500-110UM-ENG.book Page 8 Friday, March 28, 2008 11:12 AM

Korg PA 500 Specifications

General

Sequencer	16-track sequencer
Amplification	2 x 15W
MIDI	In, Out
Damper Pedal Input	Yes
Assignable Pedal/Switch	Yes
Keyboard	61 keys with velocity
Sounds	880 sounds + 56 drum kits
Styles	320 styles
Display	320 x 240 pixel color touch screen
Speakers	2 speakers in bass-reflex box
USB	USB to Host
Headphone Output	Yes
Connections	Audio In, MIDI In/Out, USB
Polyphony	80 voices
