Effect parameters
23
between these two. If you do not need to set too much
pitch shift amount, set this parameter to Slow. If you
wish to change the pitch significantly, use Fast.
HighDamp [000…100%]
Sets the damping amount in the high range.
Trim [000…127]
Sets the input level.
27. GrainSft (Grain Shifter): IFX
S.GrnSft
(Stereo Grain Shifter): MFX
This effect samples extremely brief fragments of the
sound at a specified interval, and plays them as a loop.
This is effective when used on external input sounds
that are constantly changing.
If used for an insert effect, this will be mono-in/mono-
out.
If used for the master effect, this will be stereo-in/ste-
reo-out.
BPM Sync (Duration BPM Sync) [Off, On]
Specifies whether playback of the looped waveform will
be synchronized. If this is On, the looped waveform will
play in synchronization with the tempo or MIDI clock.
TimRatio (Time Ratio)
[BPM Sync Off: 000.5…400.0% (OVER)
BPM Sync On: 012.5…400.0% (OVER)]
This specifies the length of the looped waveform rela-
tive to the “Duration” value.
Duration
[BPM Sync Off IFX: 000…500msec
BPM Sync Off MFX: 000…350msec
BPM Sync On 1/64…1/1]
Sets the duration of the grain. The length of the wave-
form is determined by this setting and the “TimRatio”
setting.
If “BPM Sync” is Off, this is set in msec units.
If “BPM Sync” is On, this is set as a timing resolution rel-
ative to the tempo specified by the [TEMPO] knob or
MIDI clock.
If you use this in an insert effect and the other in-
sert effect uses a delay or chorus effect, the wave-
form length will be limited.
If the “Duration” and “TimRatio” settings exceed
the limit, an indication of OVER will appear for
the “TimRatio.”
+
Left
Right
Sample Cycle
Dry / Wet
Dry / Wet
Wet: Mono In - Mono Out / Dry: Stereo In - Stereo Out
LFO
Grain Shifter
Left
Right
Sample Cycle
LFO Spread
Sample Cycle
Dry / Wet
Dry / Wet
Stereo In - Stereo Out
LFO
Grain Shifter
Grain Shifter
