2–2: OSC1 LFO (Oscillator 1 LFO)
18
2–2c: Frequency Modulation
These settings (KeyTrack, JS(+Y), Alternate Modulation) affect the speed of the oscillator 1 LFO.
KeyTrack (Keyboard Tracking) [–99…+99]
With positive (+) settings, the oscillator 1 LFO will become faster as you play higher on the key-
board.
With a setting of +33, the LFO speed will double as you play one octave higher on the keyboard,
and will be halved as you play one octave lower on the keyboard. Similarily, with a setting of +66,
the LFO speed will be increased to 4 times (decreased to 1/4th), and with a setting of +99 to 8
times (decreased to 1/8th).
With negative (–) settings, the oscillator 1 LFO will become slower as you play higher on the key-
board. The relation between the parameter value and the change in speed will be the opposite
from positive values.
With a “1–2: OSC” setting (☞ page 9 in this manual) of 8' the center key will be C4.
JS (+Y) (Joy Stick (+Y)) [0…99]
The higher this value is set, the faster the oscillator 1 LFO speed will become when you push the
joystick away from you.
With a setting of 99, the LFO speed will be increased by approximately 64 times when the joystick
is pushed all the way forward.
Alternate Modulation
AMS (Alternate Modulation Source) [OFF…Tempo]
Select the source that will control the frequency of the oscillator 1 LFO.
With a setting of OFF, there will be no modulation.
Intensity [–99…+99]
The time-related parameters of the LFO (“2–2a: Freq”, “2–2b: Delay, Fade”) can be temporarily
changed by the selected Alternate Modulation Source.
With settings of 16, 33, 49, 66, 82, and 99, the LFO time-related parameters will be multiplied
respectively by up to 2, 4, 8, 16, 32, and 64 times (or decreased by 1/2, 1/4, 1/8, 1/16, 1/32, or 1/
64).
If AMS is set to EG or LFO, the maximum available range of control allows the time-related
parameters to be modified over a range from 1/64th to 64 times their original values. (The LFO
allows an additional offset to be specified.)
If AMS is set to Controller, positive (+) values of this parameter will allow time-related parame-
ters to be shortened, to a maximum of 1/64th of their original time values. With negative (–) val-
ues, time-related parameters will be lengthened, to a maximum of 64 times the original values.
If AMS is set to SW1 or SW2, the time-related parameters can be shortened to as little as 1/64th or
lengthened to as great as 64 times their original value.
If AMS is set to Tempo, a setting of +16 for this parameter will cause the time-related parameters
to be shortened to half their original value when the tempo is doubled. This allows LFO speed to
track the tempo.
For details on how Alternate Modulation and the other AMS functions operate, refer to page 157
“8. Appendix” in this manual and to page 33 “About alternate modulation” in the Basic Guide.
