3–1: Key Zone (Track 1–8)
94
Sequencer P3
Here you can specify the range of note numbers and velocities for which the internal tone genera-
tor will sound by each track.
3–1: Key Zone (Track 1–8)
3–2: Key Zone (Track 9–16)
Set the Top/Bottom Key to specify the range for which each track will sound, and the Top/Bottom
Slope to specify the area over which the volume will change.
The LCD will display a solid line to indicate the range of notes that will sound, and the slope areas
will be shaded.
If two or more tracks receiving the same channel are set so that their ranges do not overlap, you
can play different sounds from different ranges of the keyboard. (Key Split)
If the slopes (the shaded portions) overlap, the sounds will overlap, and the mix of the sounds will
change as you play across the keyboard. (Positional Crossfade)
On the keyboards of the TRINITY, TRINITY V3 and TRINITY plus, you can make settings in the
range of C2–C7, on the TRINITY V3 pro, TRINITY pro in the range of E1–G7, and on the TRIN-
ITY V3 proX, TRINITY proX in the range of A0–C8 (when transpose etc. is not used).
These settings have no effect on MIDI transmission or reception. All incoming note messages will
be recorded, and all notes played by the sequencer or keyboard will be transmitted.
It is not possible to set the Bottom Key above the Top Key. Nor is it possible to make settings
that would cause the Top Slope and Bottom Slope to overlap.
3–1a: Top Key [C–1…G9]
Specifies the top key of the range in which each track will sound.
The key can also be specified from the keyboard.
3–1b: Top Slope [00…72]
Specifies the key range (12 is one octave) over which the volume will reach the original volume
from the Top Key.
This is not effective for the timbres that use Bank M programs.
With a setting of 0, the Top Key will sound at the original (maximum) volume.
With a setting of 12, the volume will gradually increase until the key one octave below the Top
Key will sound at the original volume.
With a setting of 60, the volume will gradually increase until the key five octaves below the Top
Key will sound at the original volume.
Page Menu
Track No.
3–1a
3–1b
3–1c
3–1d
Track 1
Key Zone display
Track 16
C–1~G9
3–1A
3–1B
3–1C
3–1D
Information for
the selected track
To Next Page
