118
• If you are in Combination, Sequencer, and master
effects are not applied when you raise the “S1
(Send1 (MFX1))” or “S2 (Send2 (MFX2))” of the
timbre/track, does “Return 1” or “Return 2” from
the master effect need to be raised?
....................................................................
☞PG p.47, 85
Alternatively, has “Send 1” or “Send 2” for each
oscillator of the program used by the timbre/track
been lowered?..........................................
☞PG p.45, 84
The actual send level is determined by multiplying
the send setting of each oscillator in the program
with the send setting of the timbre/track.
When you loaded data, a combination or song
does not sound correctly
• In the dialog box from which you saved the data,
did you check the check boxes for each item that
you wanted to save? ...........................................
☞p.45
• In the dialog box when saving the data, did you
check the check boxes for each item that you
wanted to save? ..........................................
☞PG p.124
• Are the bank/number of the programs used by the
song the same as when the song was created?
........................................................................
☞PG p.124
Playback does not start when you press the
[START/STOP] key in Sequencer mode
• Is the GLOBAL 2.1: MIDI, MIDI page “MIDI Clock”
set to Internal?.............................................
☞PG p.127
Can’t record in Sequencer mode
• In the GLOBAL 1.1: System, Preference page, is the
Memory Protect “Song” check box unchecked?
........................................................................
☞PG p.125
• Is the GLOBAL 2.1: MIDI, MIDI page “MIDI Clock”
set to Internal?.............................................
☞PG p.127
Arpeggiator does not start
• Is the [ARP ON/OFF] key turned on (lit)?
• If the arpeggiator does not start for a combination
or song, make sure that “Arpeggiator Run” is
checked, and that an arpeggiator is selected for
“Assign.”..........................................
☞p.28, PG p.35, 81
• Is the GLOBAL 2.1: MIDI “MIDI Clock” parameter
set to Internal?.............................................☞PG p.127
• If the [ARP ON/OFF] key does not respond in
GLOBAL 6.1: Arp.Pattern, you may have moved
here from Sampling mode or Media mode.
No sound when the [AUDIITON] key is turned on
• The Audition function is available only in Program
mode.
• If no sound is played when you turn on the
[AUDITION] key in Program mode, make sure that
the PROG 2.1: Ed-Basic, Audition page parameter
“Audition Riff” has not been turned Off
............................................................................
☞PG p.9
• If no sound is played when you turn on the
[AUDITION] key in Sampling mode, check the
following points.
Is a sample correctly assigned to the currently
selected “Index”? ..........................................
☞PG p.87
RPPR does not start
• Is the SEQ 1.1: Play/REC “RPPR” setting checked?
.........................................................................
☞PG p.51
• Are “Assign,” “Pattern Select,” and “Track” set
correctly? ..............................................
☞p.73, PG p.72
• If the GLOBAL 2.1: MIDI “MIDI Clock” parameter
set to Internal? ............................................
☞PG p.127
You converted GM/GS/XG format SMF data and
played it in Sequencer mode, but it does not sound
correctly
• Execute “GM Initialize” to initialize the settings.
.........................................................................
☞PG p.54
• Is GLOBAL 1.1: System, Preference page “Bank
Map” set to GM?.........................................
☞PG p.124
• Make sure that the “Status” is INT or BTH.
................................................................
☞p.68, PG p.62
Settings for oscillator 2 are not displayed
• Make sure that the PROG 1.1: Ed–Basic, Prog Basic
page “Mode (Oscillator Mode)” parameter is set to
Double. ...................................................
☞p.50, PG p.5
This instrument does not respond to incoming MIDI
data
• Are all MIDI cables connected correctly?
..............................................................
☞p.12, PG p.229
• Is the MIDI data being received on the channel on
which it is being transmitted?...................
☞PG p.127
This instrument does not respond correctly to
incoming MIDI data
• Are the GLOBAL 2.1: MIDI, MIDI page MIDI Filter
settings “Enable Program Change,” “Bank,”
“Combi,” “Ctrl Change,” and “AfterT” each
checked? ......................................................
☞PG p.128
• If you wish to receive MIDI exclusive messages, is
the GLOBAL 2.1: MIDI, MIDI page MIDI Filter
“Exclusive” item checked?
.......................................................................
☞PG p.129
• Does this instrument support the types of messages
that are being sent to it?
Can’t format SmartMedia; can’t save/load data
• Are you using 3.3V SmartMedia or SmartMedia
with ID?.................................................................
☞p.96
To Next Page
