121
Appendices
Specifications and options
Audio outputs
1/4" AUDIO OUTPUT (MAIN) L/MONO, R:
1/4" AUDIO OUTPUT (INDIVIDUAL) 1, 2
1/4" AUDIO OUTPUT HEADPHONE
Audio inputs (if the separately sold EXB-SMPL option is
installed)
AUDIO INPUT 1, 2
LEVEL [MIC/LINE] switch, [LEVEL] knob
Input impedance: 10 [kΩ]
Nominal level
Maximum level
Source impedance: 600 [Ω]
Control inputs
DAMPER (half-damper supported), ASSIGNABLE
SWITCH/PEDAL
Other
MIDI IN, OUT, THRU
SmartMedia slot:
Usable media: 3.3V SmartMedia (4M–128Mbyte,
including cards with ID)
AC power inlet, switch
Support for options
EXB-SMPL (one 16Mbyte 72-pin SIMM is included)
72-pin SIMM memory slots x 2 (for sample data RAM)
Dimensions (W × D × H)
61-key model: 1045.2 × 302.3 × 95.3 (mm)
76-key model: 1257.6 × 302.3 × 95.3 (mm)
Weight
61-key model: 7.8kg
76-key model: 9.2kg
Power consumption:
12W (if the EXB-SMPL option and two 32Mbyte SIMM
are installed)
Included items:
AC/AC power supply 9VAC 3.0A
Options
Expansion board
EXB-SMPL Sampling upgrade
Expression/volume pedal:
XVP-10 EXP/VOL pedal
Foot controller:
EXP-2
Damper pedal:
DS-1H
Pedal switch:
PS-1
Other:
MIDI cable
* Appearance and specifications of this product are subject to
change without notice. (Aug/01)
Output impedance 1.1 [kΩ]
(L/MONO is 550 [Ω] for mono)
Maximum output level
L/MONO, R: +12.0 [dBu]
(INDIVIDUAL)1.2: +11.6 [dBu]
Load impedance 100 [kΩ] or greater
Output impedance 33 [Ω]
Maximum output level 36 [mW]
Load impedance 33 [Ω]
LINE +3 [dBu] @ [INPUT] knob= min.
–30 [dBu] @ [INPUT] knob= max.
MIC –18 [dBu] @ [INPUT] knob= min.
–53 [dBu] @ [INPUT] knob= max.
LINE +13 [dBu] @ [INPUT] knob = min.
–20 [dBu] @ [INPUT] knob= max.
MIC –8 [dBu] @ [INPUT] knob= min.
–43 [dBu] @ [INPUT] knob= max.
