3
Introduction
Overview
Overview of the modes
The TRITON Le has a large number of functions that
let you play and edit programs and combinations,
record and play sequence data, and manage data on
media. The largest unit used to organize these func-
tions is called a mode. The TRITON Le has five modes.
If the separately sold EXB-SMPL option is installed,
Sampling mode will be added (a total of six modes),
and you will be able to record and edit samples.
Program mode
• Select and play programs
You can choose programs from rewritable banks A,
B, C, and D which contain a total of 512 programs,
and non-rewritable bank G (128 programs compati-
ble with the GM standard, and nine drum pro-
grams).
• Edit a program
Make settings for the oscillator, filter, amp, EG, LFO,
effects, and arpeggiator.
Select a multisample (the following multisamples
are available)
• 425 internal multisamples (ROM)
• Multisamples (RAM) created in Sampling mode
(if the separately sold EXB-SMPL option is
installed)
• Create drum programs using a drum kit (created
in Global mode)
Combination mode
• Select and play combinations
A combination is a set of two or more programs (a
maximum of eight), and allows you to produce
complex sounds that could not be created by an
individual program.
You can choose combinations from rewritable banks
A, B, and C which contain a total of 384 combina-
tions.
• Edit a combination
Make settings for volume, pan, layer/split etc. for
each timbre (program), and make settings for effects
and the two arpeggiators etc.
Sequencer mode
• Use the 16-track sequencer to record and playback
songs.
• Make effect settings for the song.
• You can record a performance using the
arpeggiator(s) into a song or pattern.
• You can use a cue list to set up consecutive
playback of multiple songs, and specify the number
of repeats for each song.
IFX
MFX 1
MFX 2
MEQ
Insert / Master Effect
Arpeggiator
OSC 1
Multi Sample - H
Drum Kit
Multi Sample - L
PITCH1
FILTER1 AMP1
OSC 2
Multi Sample - L
PITCH2
FILTER2
AMP2
Multi Sample - H
PROGRAM MODE
PROGRAM
IFX
MFX 1
MFX 2
MEQ
TRACK 1
TRACK 8
TRACK 2
TRACK 3
TRACK 4
TRACK 5
TRACK 6
TRACK 7
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
Insert /Master Effect
Arpeggiator - A
Arpeggiatpr - B
SEQUENCER
PROGRAM
TRACK 9
TRACK 16
TRACK 10
TRACK 11
TRACK 12
TRACK 13
TRACK 14
TRACK 15
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
IFX
MFX 1
MFX 2
MEQ
TIMBRE 1
TIMBRE 8
TIMBRE 2
TIMBRE 3
TIMBRE 4
TIMBRE 5
TIMBRE 6
TIMBRE 7
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
PROGRAM
Insert /Master Effect
Arpeggiator - A
Arpeggiatpr - B
COMBINATION MODE
GLOBAL MODE
Drum Sample / Sample - L
Drum Sample / Sample - H
Key
Assign
ARPEGGIATOR PATTERN
User Pattern: P0 - 4
DRUM KIT
User Pattern: U00 - 215
Sample
Sample
SAMPLING MODE (if the separately sold EXB-SMPL option is installed)
Sample
Sample
Sample
Sample
IFX
Insert Effect
AUDIO INPUT
1
AUDIO INPUT
2
MEDIA MODE
Multi Sample
