VP-427X1 – Operating and Controlling VP-427X1
13
Setting OSD Parameters
VP-427X1 enables adjusting OSD parameters for your convenience via the OSD MENU
buttons.
To set the OSD parameters:
1. On the front panel press MENU. The menu appears.
2. Click OSD and define the OSD parameters according to the information in the following
table:
Menu Item
Function
H-Position
Set the horizontal position of the OSD.
V-Position
Set the vertical position of the OSD.
Timer
Set the timeout period to Off or up to 60 seconds (default 10).
Transparency
Set the OSD background between 100 (transparent) and 0 (opaque).
Display
Select the information displayed on-screen during operation:
Info (default) – the information appears for 10 seconds.
On – the information appears constantly.
Off – the information does not appear.
OSD parameters are set.
Managing EDID via OSD
VP-427X1 enables managing the EDID via the OSD MENU buttons.
Uploading the EDID
To upload EDID:
1. On the front panel press MENU. The menu appears.
2. Click EDID Manage and select the parameters according to the information in the
following table:
Menu Item
Function
EDID on HDBT
Select one of the following EDID sources and then press enter:
• A built-in EDID file: Def. 1080P, Def.1080P (AUD), Def. 4K
(3G), Def. 4K (3G - AUD).
• The HDMI Output.
• An external file (see Uploading EDID from an External File
on page 14).
EDID on HDMI
Select one of the EDID sources and then press enter:
• A built-in EDID file: Def. 1080P, Def.1080P (AUD), Def. 4K
(3G), Def. 4K (3G - AUD), Def. 4K (6G), Def. 4K (6G - AUD)
• The HDMI Output.
• An external file (see Uploading EDID from an External File
on page 14).
The selected EDID is sent to the input.
