Kramer VP-427X1

Kramer Electronics Ltd.
VP-427X1 – Protocol 3000
59
Function
Description
Syntax
Parameters/Attributes
Example
VID-RES
Set output resolution.
“Set” command with
is_native=ON sets
native resolution on
selected output
(resolution index sent =
0). Device sends as
answer actual VIC ID of
native resolution.
To use “custom
resolutions” (entries
100-105 In View
Modes), define them
using the DEF-RES
command.
COMMAND
#VID-RESio_mode,io_index,is_native,resolution<CR>
FEEDBACK
~nn@VID-RESio_mode,io_index,is_native,resolution<CR><LF
>
io_mode – Output
1 – Output
io_index – 1
is_native – Native resolution flag
0 – Off
resolution – Resolution index
200= Native
201=640x480
202= 800x600
203=1024x768
204=1280x768
205=1360x768
206=1280x720
207=1280x800
208=1280x1024
209=1440x900
210=1400x1050
211=1680x1050
212=1600x1200
213=1920x1080
214=1920x1200
215=2560x1600
216=2560x1440
217=480p
218=576p
219=720p50
220=720p60
221=1080p24
222=1080p25
223=1080p30
224=1080p50
225=1080p60
226=4K24
227=4K25
228=4K30
229=4K50
230=4K60
Set output resolution:
#VID-RES1,1,0,1<CR>
VID-RES?
Get output resolution.
“Get” command with
is_native=ON returns
native resolution VIC,
with is_native=OFF
returns current
resolution.
To use “custom
resolutions” (entries
100-105 In View
Modes), define them
using the DEF-RES
command.
COMMAND
#VID-RES?io_mode,io_index,is_native<CR>
FEEDBACK
~nn@VID-RES?io_mode,io_index,is_native,resolution<CR><L
F>
io_mode – Input/Output
0 – Input
1 – Output
io_index – Number that indicates
the specific input or output port:
1-N (N= the total number of input or
output ports)
is_native – Native resolution flag
0 – Off
1 – On
resolution – Resolution index
io_mode – Output
1 – Output
io_index – 1
is_native – Native resolution flag
0 – Off
resolution – Resolution index
200= Native
201=640x480
202= 800x600
203=1024x768
204=1280x768
205=1360x768
206=1280x720
207=1280x800
208=1280x1024
209=1440x900
210=1400x1050
211=1680x1050
212=1600x1200
213=1920x1080
214=1920x1200
215=2560x1600
216=2560x1440
217=480p
218=576p
219=720p50
220=720p60
221=1080p24
222=1080p25
223=1080p30
224=1080p50
225=1080p60
226=4K24
227=4K25
228=4K30
229=4K50
230=4K60
Set output resolution:
#VID-RES?1,1,1<CR>
VMUTE
Set enable/disable
video on output.
COMMAND
#VMUTEout_index,flag<CR>
FEEDBACK
~nn@VMUTEout_index,flag<CR><LF>
out_index – 1
flag – Video Mute
0 – Video enabled
1 – Video disabled
Disable the video output on
OUT 2:
#VMUTE1,0<CR>
VMUTE?
Get video on output
status.
COMMAND
#VMUTE?out_index<CR>
FEEDBACK
~nn@VMUTEout_index,flag<CR><LF>
out_index – 1
flag – Video Mute
0 – Video enabled
1 – Video disabled
Get video on output status:
#VMUTE?1<CR>
