Kramer VP-427X1

Kramer Electronics Ltd.
VP-427X1 – Protocol 3000
60
Function
Description
Syntax
Parameters/Attributes
Example
X-AUD-LVL
Set audio level of a
specific signal.
This is an Extended
Protocol 3000
command.
COMMAND
#X-AUD-LVL<direction_type>. <port_format>. <port_index>.
<signal_type>. <index>,audio_level<CR>
FEEDBACK
~nn@X-AUD-LVL<direction_type>. <port_format>.
<port_index>. <signal_type>. <index>,audio_level<CR><LF>
The following attributes comprise
the signal ID:
▪ <direction_type> –
Direction of the port:
o OUT – Output
▪ <port_format> – Type of
signal on the port:
o HDMI
▪ <port_index> – 1
▪ <signal_type> – Signal ID
attribute:
o AUDIO
▪ <index> – 1
audio_level – Audio level (range
between 0 to 100) depending of the
ability of the product
Set the audio level of HDMI
output to 10:
#X-AUD-LVLOUT.HDMI.1
.AUDIO.1,10<CR>
X-AUD-
LVL?
Get audio level of a
specific signal.
This is an Extended
Protocol 3000
command.
COMMAND
#X-AUD-LVL?<direction_type>. <port_format>. <port_index>.
<signal_type>. <index><CR>
FEEDBACK
~nn@X-AUD-LVL<direction_type>. <port_format>.
<port_index>. <signal_type>. <index>,audio_level<CR><LF>
The following attributes comprise
the signal ID:
▪ <direction_type> –
Direction of the port:
o OUT – Output
▪ <port_format> – Type of
signal on the port:
o HDMI
▪ <port_index> – 1
▪ <signal_type> – Signal ID
attribute:
o AUDIO
▪ <index> – 1
audio_level – Audio level (range
between 0 to 100) depending of the
ability of the product
Get the audio level of HDMI
output:
#X-AUD-LVL?OUT.HDMI.
1.AUDIO.1<CR>
X-AV-SW-
MODE
Set auto-switch mode
per output.
This is an Extended
Protocol 3000
command.
COMMAND
#X-AV-SW-MODE<direction_type>. <port_format>.
<port_index>. <signal_type>. <index>,connection_mode<CR>
FEEDBACK
~nn@X-AV-SW-MODE<direction_type>. <port_format>.
<port_index>. <signal_type>.
<index>,connection_mode<CR><LF>
The following attributes comprise
the signal ID:
▪ <direction_type> –
Direction of the port:
o OUT – Output
▪ <port_format> – Type of
signal on the port:
o HDMI
▪ <port_index> – 1
▪ <signal_type> – Signal ID
attribute:
o VIDEO
▪ <index> – 1
connection_mode – Connecton
mode
0 – manual
1 – Auto Scan
2 – last connected
Set auto switch mode for the
output to last connected:
#X-AV-SW-MODEOUT.HDM
I.1.VIDEO.1,2<CR>
X-AV-SW-
MODE?
Get auto-switch mode.
This is an Extended
Protocol 3000
command.
COMMAND
#X-AV-SW-MODE?<direction_type>. <port_format>.
<port_index>. <signal_type>. <index><CR>
FEEDBACK
~nn@X-AV-SW-MODE<direction_type>. <port_format>.
<port_index>. <signal_type>.
<index>,connection_mode<CR><LF>
The following attributes comprise
the signal ID:
▪ <direction_type> –
Direction of the port:
o OUT – Output
▪ <port_format> – Type of
signal on the port:
o HDMI
▪ <port_index> – 1
▪ <signal_type> – Signal ID
attribute:
o VIDEO
▪ <index> – 1
connection_mode – Connecton
mode
0 – manual
1 – Auto Scan
2 – last connected
Get auto switch mode for the
output:
#X-AV-SW-MODE?OUT.HD
MI.1.VIDEO.1<CR>
X-MUTE
Set mute ON/OFF on a
specific signal.
This command is
designed to Mute a
Signal. This means that
it could be applicable
on any type of signal.
Could be audio, video
and maybe IR, USB or
data if this capability is
supported by the
product.
This is an Extended
Protocol 3000
command.
COMMAND
#X-MUTE<direction_type>. <port_format>. <port_index>.
<signal_type>. <index>,state<CR>
FEEDBACK
~nn@X-MUTE<direction_type>. <port_format>. <port_index>.
<signal_type>. <index>,state<CR><LF>
The following attributes comprise
the signal ID:
▪ <direction_type> –
Direction of the port:
o OUT – Output
▪ <port_format> – Type of
signal on the port:
o HDMI
▪ <port_index> – 1
▪ <signal_type> – Signal ID
attribute:
o VIDEO
o AUDIO
▪ <index> – 1
state – OFF/ON (not case
sensitive)
Mute the audio on the HDMI
output:
#X-MUTEout.hdmi.1.au
dio.1,on<CR>
