KStar MEMO PLUS RT II (MP9100RTII-0.9) 1-3K User Manual

50
Battery aged
When replace battery, contact
franchiser to get battery and
relative assembly
UPS doesn’t
startup after
pressing the ON
key
Didn’t press the
combination keys of
“on”
Press the two keys at the same
time
UPS has no battery
connected or battery
voltage low and too
many loads connected
Connect UPS battery well, if
battery voltage low, please turn
off UPS and remove some loads,
then start UPS
Fault occurs inside
UPS
Contact supplier for servicing
The icon of
charger status on
LCD display
flashes and buzzer
beeps once per
second
Charger doesn’t work
normally or battery
aged
Contact supplier for servicing
The following table describes typical faulty conditions.
Table 23. Fault code for RT type
Fault Kind
Fault type
Operating Mode before fault
Byp Mode
Line Mode
Bat Mode
BatTest Mode
Eco Mode
Bus Fault
P Bus High
05
01
40
80
N Bug High
25
21
41
81
P Bus Low
35
31
70
90
N Bus Low
55
51
71
91
Bus unbalance
82
83
84
85
Soft fail
62
Inv Fault
High
04
24
42
86
Low
14
34
52
96
Soft fail
63
Bus discharge fail
61
Over Heat
33
06
08
43
53
INV short
16
02
44
73
OverLoad
03
09
45
65
Fan Fault
36
28
38
46
66
Charger Fault
07
17
27
Bat Over
11
12
13
InvRelaySht
76
LineNTCBreak
98
Shutdown Fault
97
