22 TECHNICAL DATA 108

Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft) Loctite

2701

Nut, rim lock M8 10 Nm (7.4 lbf ft) –

Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –

Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –

Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft) –

Screw, chain sliding piece M8 15 Nm (11.1 lbf ft) –

Screw, engine brace M8 33 Nm (24.3 lbf ft) –

Screw, fork stub M8 15 Nm (11.1 lbf ft) –

Screw, front brake caliper M8 25 Nm (18.4 lbf ft)

Loctite

243™

Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –

Screw, side stand attachment M8 45 Nm (33.2 lbf ft) Loctite

2701

Screw, subframe M8 35 Nm (25.8 lbf ft) Loctite

2701

Screw, top steering stem M8 20 Nm (14.8 lbf ft) –

Screw, top triple clamp M8 20 Nm (14.8 lbf ft) –

Engine attachment bolt M10 60 Nm (44.3 lbf ft) –

Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –

Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –

Screw, handlebar support M10 40 Nm (29.5 lbf ft)

Loctite

243™

Nut, fuel pump fixation M12 15 Nm (11.1 lbf ft) –

Screw, bottom shock absorber M12 80 Nm (59 lbf ft) Loctite

2701

Screw, top shock absorber M12 80 Nm (59 lbf ft) Loctite

2701

Nut, seat fixing M12x1 20 Nm (14.8 lbf ft) –

Nut, swingarm pivot M16x1.5 100 Nm (73.8 lbf ft) –

Nut, rear wheel spindle M20x1.5 80 Nm (59 lbf ft) –

Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft) –

Screw-in nozzles, cooling system M20x1.5 12 Nm (8.9 lbf ft)

Loctite

243™

Screw, front wheel spindle M24x1.5 45 Nm (33.2 lbf ft) –
