KTM 500 EXC User Manual

4 VIEW OF VEHICLE 13
4.2 View of vehicle, rear right (example)
S00016-10
1 Fork rebound adjustment and spring preload adjustment
2 Clutch lever ( p. 16)
3 Light switch ( p. 16)
3 Turn signal switch ( p. 17)
3 Horn button ( p. 16)
4 Emergency OFF switch ( p. 17)
4 Electric starter button ( p. 17)
5 Throttle grip ( p. 16)
6 Hand brake lever ( p. 16)
7 Ignition lock ( p. 17)
8 Shock absorber rebound adjustment
9 Shock absorber compression adjustment
10 Foot brake lever ( p. 26)
11 Kick starter ( p. 25)

KTM 500 EXC Specifications

General

Engine Type	Single cylinder, 4-stroke
Bore x Stroke	95 mm x 72 mm
Starter	Electric starter
Transmission	6-speed
Cooling	Liquid cooled
Rear Suspension	WP XPLOR PDS shock absorber
Ground Clearance	355 mm
Seat Height	960 mm
ABS	No
Displacement	510.9 cm³
Fuel System	Keihin EFI, throttle body 42 mm
Frame	Central double-cradle type 25CrMo4 steel
Front Suspension	WP Xplor 48, USD fork
Front Brake	260 mm disc
Rear Brake	220 mm disc
Fuel Tank Capacity	8.5 liters
