KTM 530 EXC - CONTROLS; Handlebar Controls

CONTROLS 14
5CONTROLS
5.1Clutch lever
500133-10
The clutch lever  is fitted on the left side of the handlebar.
The clutch is hydraulically operated and self-adjusting.
5.2Hand brake lever
400196-10
Hand brake lever  is located on the right side of the handlebar.
The hand brake lever is used to activate the front brake.
5.3Emergency OFF switch
500144-10
The emergency OFF switch  is fitted on the left side of the handlebar.
Possible states
Ignition off – In this position, the ignition circuit is interrupted, a run-
ning engine stops, and a non-running engine will not start.
Ignition on – In this position, the ignition circuit is closed, and the
engine can be started.
5.4Ignition switch
300396-10
The ignition switch  is on the right behind the headlight mask.
Possible states
Ignition off – In this position, the ignition circuit is interrupted, a run-
ning engine stops, and a non-running engine will not start.
Ignition on – In this position, the ignition circuit is closed, and the
engine can be started.
5.5Electric starter button
500144-12
Electric starter button  is fitted on the right side of the handlebar.
Possible states
• Electric starter button is in home position
• Electric starter button is pressed – In this position, the electric starter is actu-
ated.
