CONTROLS 15
5.6Light switch
500142-10
Light switch is fitted on the left side of the handlebar.
Possible states
Low beam on – Light switch is turned downward. In this position, the
low beam and tail light are switched on.
High beam on – Light switch is turned upward. In this position, the
high beam and tail light are switched on.
5.7Highlight flasher button
500143-10
Headlight flasher button is fitted on the left side of the handlebar.
Possible states
• Headlight flasher button is in home position
• Headlight flasher button is pressed – The headlight flasher is activated in this
position.
5.8Horn button
500142-11
Horn button is fitted on the left side of the handlebar.
Possible states
• Horn button is in home position
• Horn button is pressed – The horn is sounded in this position.
5.9Flasher switch
500142-12
Flasher switch is fitted on the left side of the handlebar.
Possible states
Flasher light off
Flasher light, left, on – Flasher switch is pressed to the left. The flasher
switch returns to the middle position after activation.
Flasher light, right, on – Flasher switch is pressed to the right. The
flasher switch returns to the middle position after activation.
To switch off the flasher, push the flasher switch toward the switch housing.
5.10Overview of indicator lamps
500147-01
Possible states
High beam indicator lamp lights up blue – High beam is switched on.
Flasher indicator lamp flashes green – Flasher light is switched on.
