TECHNICAL DATA - ENGINE TIGHTENING TORQUES 87
Screw, cylinder head M10x1.25 Tightening sequence:
Tighten diagonally, begin-
ning with the rear screw on
the chain shaft.
Step 1
10 Nm (7.4 lbf ft)
Step 2
30 Nm (22.1 lbf ft)
Step 3
50 Nm (36.9 lbf ft)
lubricated with engine oil
Nut, rotor M12x1 60 Nm (44.3 lbf ft) –
Spark plug M12x1.25 15… 20 Nm (11.1…
14.8 lbf ft)
–
Gear oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft) –
Plug, SLS M12x1.5 20 Nm (14.8 lbf ft) –
Oil pressure control valve plug M12x1.5 20 Nm (14.8 lbf ft) –
Plug, rocker arm M14x1.25 20 Nm (14.8 lbf ft) –
Plug, gear oil screen M16x1.5 20 Nm (14.8 lbf ft) –
Plug, engine oil screen M17x1.5 20 Nm (14.8 lbf ft) –
Nut, inner clutch hub M18x1.5 80 Nm (59 lbf ft) –
Nut, primary gear M20LHx1.5 100 Nm (73.8 lbf ft)
Loctite
®
243™
Plug, timing chain tensioner M24x1.5 30 Nm (22.1 lbf ft) –
