21 TECHNICAL DATA
110
Screw, stator M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, tensioning rail M6x30 10 Nm (7.4 lbf ft)
Loctite
®
2701™
Screw, thermostat case M6 10 Nm (7.4 lbf ft)
Screw, valve cover M6 10 Nm (7.4 lbf ft)
Screw, water pump cover M6 10 Nm (7.4 lbf ft)
Screw, water pump wheel M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Intake channel vacuum connection M6x0.75 2.5 Nm (1.84 lbf ft)
Loctite
®
2701™
Oil nozzle for piston cooling M6x0.75 4 Nm (3 lbf ft)
Nut, exhaust flange M8 20 Nm (14.8 lbf ft)
Copper paste
Screw plug, locking screw M8 15 Nm (11.1 lbf ft)
Screw, rocker arm shaft M8 15 Nm (11.1 lbf ft)
Setscrew, camshaft bearing bridge M8 6 Nm (4.4 lbf ft)
Loctite
®
243™
Stud, exhaust flange M8 15 Nm (11.1 lbf ft)
Loctite
®
243™
Screw, cylinder head M10 Tightening sequence:
Tighten diagonally, beginning with
the rear screw on the timing chain
shaft.
1st stage
15 Nm (11.1 lbf ft)
2nd stage
30 Nm (22.1 lbf ft)
3rd stage
45 Nm (33.2 lbf ft)
4th stage
60 Nm (44.3 lbf ft)
Thread greased
Oil line for oil pressure sensor M10x1 10 Nm (7.4 lbf ft)
Oil pressure sensor M10x1 10 Nm (7.4 lbf ft)
Screw plug, oil channel M10x1 15 Nm (11.1 lbf ft)
Loctite
®
243™
Screw plug, oil channel, for oil
radiator
M10x1 15 Nm (11.1 lbf ft)
Screw plug, water pump drain hole M10x1 15 Nm (11.1 lbf ft)
Screw, unlocking of timing chain
tensioner
M10x1 10 Nm (7.4 lbf ft)
Spark plug outside M10x1 11 Nm (8.1 lbf ft)
Spark plug inside M12x1.25 18 Nm (13.3 lbf ft)
Coolant temperature sensor on the
cylinder head
M12x1.5 12 Nm (8.9 lbf ft)
Oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft)
Screw plug, oil pressure control
valve
M12x1.5 20 Nm (14.8 lbf ft)
Screw plug, oil channel M14x1.5 15 Nm (11.1 lbf ft)
Loctite
®
243™
