CONTROLS 6
25
6.20.15 Service interval display
S04394-10
– Press the + or ‑ button repeatedly until SER is shown on the
combination instrument.
SER shows the remaining kilometers until the next service is due.
6.20.16 Tachometer
S04399-01
– Press the + or ‑ button repeatedly until RPM is shown on the
combination instrument.
Guideline
Speed per symbol approx.
8 1,000 rpm
88 3,000 rpm
888 4,000 rpm
8888 5,000 rpm
88888 7,000 rpm
888888 9,000 rpm
RPM shows the current engine speed.
Info
Before the first service, the tachometer always flashes
with a slow frequency (5 Hz) when the engine speed
reaches 6500 rpm.
The tachometer flashes with a slow frequency (5 Hz)
in the following cases: The coolant temperature is
lower than 35 °C and the engine speed has reached
6500 rpm, or the recommended shift speed of
8000 rpm has been reached.
The tachometer flashes with a fast frequency (10 Hz)
when the maximum engine speed is reached.
6.20.17 Odometer
S04379-01
– Press the + or ‑ button repeatedly until ODO is shown on the
combination instrument.
ODO shows the motorcycle's total mileage.
