TECHNICAL DATA - CHASSIS TIGHTENING TORQUES 102
Spoke nipple M4.5 5… 6 Nm (3.7… 4.4 lbf ft) –
Screw, battery terminal M5 2.5 Nm (1.84 lbf ft) –
Screw, shock absorber adjusting ring M5 5 Nm (3.7 lbf ft) –
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –
Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –
Screw, ball joint of push rod on foot
brake cylinder
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screws, throttle grip M6 3 Nm (2.2 lbf ft) –
Fuel connection on fuel pump M8 10 Nm (7.4 lbf ft) –
Nut, foot brake lever stop M8 20 Nm (14.8 lbf ft) –
Nut, rear sprocket screw M8 35 Nm (25.8 lbf ft)
Loctite
®
243™
Nut, rim lock M8 10 Nm (7.4 lbf ft) –
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –
Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –
Screw, bottom triple clamp M8 18 Nm (13.3 lbf ft) –
Screw, chain sliding piece M8 15 Nm (11.1 lbf ft) –
Screw, fork stub M8 15 Nm (11.1 lbf ft) –
Screw, front brake caliper M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, fuel tank M8 15 Nm (11.1 lbf ft) –
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –
Screw, side stand attachment M8 35 Nm (25.8 lbf ft)
Loctite
®
243™
Screw, subframe M8 30 Nm (22.1 lbf ft)
Loctite
®
243™
Screw, top steering stem M8 17 Nm (12.5 lbf ft)
Loctite
®
243™
Screw, top triple clamp M8 22 Nm (16.2 lbf ft) –
Nut, fuel tank attachment M10 10 Nm (7.4 lbf ft) –
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –
Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –
Screw, cross bar M10 45 Nm (33.2 lbf ft) –
Screw, engine bracket screw M10 60 Nm (44.3 lbf ft) –
Screw, foot brake lever M10 30 Nm (22.1 lbf ft)
Loctite
®
243™
Screw, footrest bracket M10 45 Nm (33.2 lbf ft)
Loctite
®
243™
Screw, handlebar support M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
Screw, upper subframe M10 45 Nm (33.2 lbf ft) –
Nut, fuel pump fixation M12 15 Nm (11.1 lbf ft) –
Screw, bottom shock absorber M12 80 Nm (59 lbf ft)
Loctite
®
243™
Screw, top shock absorber M12 80 Nm (59 lbf ft)
Loctite
®
243™
Nut, swingarm pivot M14x1.5 75 Nm (55.3 lbf ft) –
Nut, rear wheel spindle M20x1.5 80 Nm (59 lbf ft) –
Screw, front wheel spindle M20x1.5 35 Nm (25.8 lbf ft) –
Screw, top steering head M20x1.5 12 Nm (8.9 lbf ft) –
