TECHNICAL DATA - ENGINE TIGHTENING TORQUES 96
Jet, crank chamber ventilation M4 2 Nm (1.5 lbf ft)
Loctite
®
243™
Oil jet for alternator cooling M4 2 Nm (1.5 lbf ft)
Loctite
®
243™
Oil jet for balancer shaft lubrication M4 2 Nm (1.5 lbf ft)
Loctite
®
243™
Oil nozzle for conrod bearing lubrica-
tion
M4 2 Nm (1.5 lbf ft)
Loctite
®
243™
Screw, oil jet for piston cooling M4 2 Nm (1.5 lbf ft)
Loctite
®
243™
Locking screw for bearing M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Oil jet for cam lever lubrication M5 3 Nm (2.2 lbf ft)
Loctite
®
243™
Oil jet for clutch lubrication M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Oil jet, piston cooling M5 2 Nm (1.5 lbf ft)
Loctite
®
243™
Screw cap, oil channel in alternator
cover
M5 3 Nm (2.2 lbf ft)
Loctite
®
243™
Screw, clutch spring M5 6 Nm (4.4 lbf ft) –
Screw, crankshaft position sensor M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, locking lever M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, oil pump cover M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, stator M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Nut, cylinder head M6 10 Nm (7.4 lbf ft) Lubricated with engine oil
Nut, water-pump wheel M6 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, alternator cover M6 6 Nm (4.4 lbf ft) –
Screw, clutch cover M6 10 Nm (7.4 lbf ft) –
Screw, clutch slave cylinder M6 10 Nm (7.4 lbf ft) –
Screw, engine case M6 10 Nm (7.4 lbf ft) –
Screw, exhaust flange M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, oil filter cover M6 10 Nm (7.4 lbf ft) –
Screw, shift drum locating M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, shift lever M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, starter motor M6 10 Nm (7.4 lbf ft) –
Screw, timing chain guide rail M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, timing chain securing guide M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, valve cover M6 8 Nm (5.9 lbf ft) –
Screw, water pump cover M6 10 Nm (7.4 lbf ft) –
Stud, cylinder head M6 10 Nm (7.4 lbf ft) –
Screw, camshaft bearing bridge M7x1 14 Nm (10.3 lbf ft) Lubricated with engine oil
Screw plug, crankshaft location M8 10 Nm (7.4 lbf ft) –
Screw, timing chain tensioning rail M8 15 Nm (11.1 lbf ft)
Loctite
®
243™
Screw, engine sprocket M10 60 Nm (44.3 lbf ft)
Loctite
®
2701
Plug, oil channel M10x1 15 Nm (11.1 lbf ft)
Loctite
®
243™
Rotor screw M10x1 70 Nm (51.6 lbf ft) Thread, oiled with engine
oil/cone degreased
Screw plug, cam lever axis M10x1 10 Nm (7.4 lbf ft) –
Screw, unlocking of timing chain ten-
sioner
M10x1 10 Nm (7.4 lbf ft) –
Spark plug M10x1 10… 12 Nm (7.4…
8.9 lbf ft)
–
Nut, cylinder head M10x1.25 Tightening sequence:
Tighten diagonally.
1st tightening stage
10 Nm (7.4 lbf ft)
2nd tightening stage
30 Nm (22.1 lbf ft)
3rd tightening stage
50°
Thread, oiled with engine
oil/cone greased
Stud, cylinder head M10x1.25 20 Nm (14.8 lbf ft)
Loctite
®
243™
