Kubota G23 Assembly Instructions

9
ENGLISH
[4]COVER ASSEMBLY
BPARTS LIST
Ref.
No.
Part Number Description Qty
(1) K6312-6365-2 HANDLE, FRONT 1
(2) K6312-6364-0 HANDLE, REAR 1
(3) K6312-6391-2 COVER, REAR CENTER 1
(4) K6312-6394-2 COVER, REAR CENTER2 1
(5) 01754-50825 BOLT, FLANGE 4
(6) 01754-50635 BOLT, FLANGE 4
(7) 02751-50060 NUT, FLANGE 4
(8) 01754-50812 BOLT, FLANGE 2
(9) 02751-50080 NUT, FLANGE 14
(10) K6312-6392-3 COVER, FRONT LEFT 1
(11) K6312-6393-3 COVER, FRONT RIGHT 1
(12) K6312-6396-3 COVER, REAR LEFT 1
(13) K6312-6397-3 COVER, REAR RIGHT 1
(14) K6313-6398-0 COLLAR 6
(15) K1211-5436-0 SCREW, BUTTON 12
(16) K6312-6441-0 SPONGE, DUST 5

Kubota G23 Specifications

General

Engine Power	23 HP
Transmission	Hydrostatic
Cutting Width	48 inches
Fuel Type	Diesel
Drive	2WD
Number of Blades	3
Engine Type	Diesel
Fuel Capacity	6.3 gallons
