4.3 Pallet fork (option for the quick attach
coupler)
Loader model LA340 and LA340S
Rated capacity at the center of the forks
109 kg
(240 lbs)
4.3.1 Assembling the pallet fork (option for
the quick attach coupler)
1. Install the pallet fork to the middle of the frame.
Fit the lower hook of the pallet fork to the center
notch of the frame.
(1) Fork
2. Slide the fork to the desired position.
(1) Fork
3. Push the lock lever and slide the fork slightly until
the lock pin engages with one of the notches to lock
the folk.
[A] Unlock
[B] Lock
(1) Lock lever
4. Install the other fork using the same procedures.
DISMOUNTING THE LOADER
WARNING
To avoid personal injury, death, or machine
damage:
