REINSTALLING THE LOADER
HOW TO REINSTALL THE
LOADER
WARNING
To avoid personal injury or death:
• When starting the engine and operating the
loader-control-valve, always sit in the operator's
seat.
1. Slowly drive the tractor between the side frames of
the loader until the rear portion of both side frames
touches the main frames as shown in the following
figures.
(1) Side frame
(2) Main frame
[A] LH
[B] RH
(A) 150 mm to 200 mm
(B) Center of side frames
2. Stop the engine and unfasten the seat belt.
3. Remove the protective cap.
(1) Protective caps
HOW TO REINSTALL THE LOADER REINSTALLING THE LOADER
To Next Page
