(1) PTO clutch lever
(A) On (engage)
(B) Off (disengage)
2. Lower all implements to the ground.
See 1. Hydraulic control on page 84.
(1) Hydraulic control lever
(A) Down
(B) Slow down
(C) Neutral
(D) Slow up
(E) Up
3. Place all control levers in their neutral positions.
4. Set the parking brake.
See “To set the parking brake” in 3.1 How to use
the parking brake on page 48.
(1) Brake pedal
(2) Parking brake lock pedal
(A) Depress
(B) Push down parking brake
lock pedal while depressing
brake pedal
5. Stop the engine.
See STOPPING THE ENGINE on page 60.
6. Remove the starter key.
7. If it is necessary to park the tractor on an incline, be
sure to chock the wheels to prevent accidental
rolling of the tractor.
TECHNIQUES FOR OPERATING
THE TRACTOR
1. Differential lock
WARNING
To avoid serious injury or death due to loss of
steering control:
• Do not operate the tractor at high speed with
differential lock engaged.
• Do not turn with the differential lock engaged.
• Be sure to release the differential lock before
turning the machine in field conditions.
If one of the rear wheels should slip, depress the
differential-lock-pedal. Both wheels will then turn
together, which reduce slippage of the rear wheels.
The differential lock is maintained only while the
differential-lock-pedal is depressed.
(1) Differential lock pedal
(A) Press to engage
(B) Release to disengage
IMPORTANT :
• When using the differential lock, always slow
the engine down.
• To prevent damage to power train, do not
engage the differential lock when one wheel is
spinning and the other is completely stopped.
• If the differential lock cannot be released in the
preceding manner, alternately press the speed-
control-pedal forward and backward slightly.
OPERATING THE TRACTOR TECHNIQUES FOR OPERATING THE TRACTOR
