3-POINT HITCH AND DRAWBAR
OVERVIEW OF 3-POINT HITCH AND DRAWBAR
(1) Top link
(2) Lifting rod (left)
(3)
Check chains
(4) Turnbuckle
(5) Lower link
(6) Top link holder
(7) Lifting rod (right)
(8) Hitch
(9) Holder plate
Use the holder plate to hold the lower link higher while mowing with mid-mount mower only over uneven terrain.
(9) Holder plate
