SPECIFICATIONS OF THE BACKHOE
BACKHOE SPECIFICATIONS
1. Dimensions of the backhoe
Model BT603
(A) Transport height
1719 mm
(67.7 in.)
(B) Stabilizer spread-transport
1296 mm
(51.0 in.)
(C) Ground clearance
240 mm
(9.4 in.)
(E) Overall width
1128 mm
(44.4 in.)
(F) Maximum digging depth
1889 mm
(74.4 in.)
(G) Digging depth, 2 ft. flat bottom
1842 mm
(72.5 in.)
(H) Digging depth, 8 ft. flat bottom
1059 mm
(41.7 in.)
(J) Operating height, fully raised
2539 mm
(100 in.)
(K) Loading height
1533 mm
(60.4 in.)
(L) Loading reach
1016 mm
(40.0 in.)
(M) Reach from swing pivot
2612 mm
(102.8 in.)
(N) Swing pivot to rear axle center line
726 mm
(28.6 in.)
(P) Bucket rotation 180 deg.
(R) Stabilizer spread-operating
1862 mm
(73.3 in.)
(A3) Angle of departure per SAE J1234 20.1 deg.
(U) Leveling angle 11 deg.
Swing arc 140 deg.
NOTE :
• The specifications are taken with KUBOT
A BX23S tractor. (Tire size: Front 18X8.5-10, Rear 26X12.00-12)
BACKHOE SPECIFICATIONS SPECIFICATIONS OF THE BACKHOE
BX23S, LA340, BT603
