IMPLEMENT LIMITATIONS
IMPLEMENT LIMITATION TABLES
IMPORTANT :
The KUBOT
A Tractor has been thoroughly tested for proper performance with implements sold or approved
by KUBOTA. Do not use the following implements:
• Implements which are not sold or approved by KUBOTA
• Implements which exceed the maximum specifications listed in the following table
• Implements which are otherwise unfit for use with the KUBOTA Tractor
These implements may result in malfunctions or failures of the tractor, damage to other property, and injury
to the operator or others.
NOTE :
Any malfunctions or failures of the tractor resulting from use with improper implements are not covered by
the warranty.
Model BX23S
Tread (max. width)
Front
930 mm
(36.6 in.)
Rear
820 mm
(32.2 in.)
Lower link end max. lifting weight W0
550 kg
(1210 lbs.)
Actual figures
Implement weight W1 and / or size As in “Implement weight list”
Max. hitch load W2
250 kg
(550 lbs.)
Trailer loading weight W3 (Max. capacity)
800 kg
(1765 lbs.)
Total weight W4
1100 kg
(2425 lbs.)
Lower link end max. lifting weight W0
The max. allowable load which can be put on the lower link end
Implement weight W1
The implement's weight which can be put on the lower link
Max. hitch load W2
The max. loading weight for hitching
Trailer loading weight W3
The max. loading weight for trailer (without trailer's weight)
Total weight W4
The max. loading weight for trailer with trailer's weight
NOTE :
• Implement size may vary depending on soil operating conditions.
•
Strictly follow the instructions outlined in the operator’s manual of the mounted or trailed machinery or
trailer, and do not operate the combination tractor-machine or tractor-trailer unless all instructions have
been followed.
