Job
Printer Driver 10-2
Job Storage (e-MPS) options
Storage location Access code
required
When job is
printed
When job is
deleted from
memory
Custom box SSD Optional password When printed from
operation panel
When manually
deleted or up to 31
days
Quick copy SSD or SD card No When sent from the
computer
When printing
system is turned
off, or storage
device is full, or job
retention date has
passed
Proof and hold SSD, RAM disk, or
SD card
No One print when job
is sent; remaining
prints later
When printing
system is turned
off, or job retention
date has passed
Private print SSD, RAM disk, or
SD card
Yes When access code
is entered at
operation panel
When printing
system is turned
off, or after printing,
or job retention
date has passed
Job storage SSD or SD card Optional When printed from
operation panel
When manually
deleted
Custom Box
With this feature, you can store print jobs until they are printed from the printing
system's operation panel. You can print one or more jobs from the storage
device.
Print jobs can be deleted after printing or saved on the storage device for 1-31
days.
Custom boxes must be set up for each user at the printing system's home page
and in the SSD Settings dialog box, accessed from Device Settings. The
maximum number of custom boxes is 1000.
Storing a Job in a Custom Box
1
In the Job tab, click the Job storage (e-MPS) icon.
2
In the Type list, select Custom box.
3
Click Settings.
4
Select a Custom Box Settings option:
Select Use specific box number, and type the box number and password.
Select Prompt for box number, and click OK. When starting to print, the
Custom Box dialog box appears. Type a box number from the Defined
custom boxes list. If a password was set, type the password.
Select Display box number list, and click OK. When starting to print, the
Custom Box dialog box appears. Select a box from the list. If a password

Table of Contents

Other manuals for Kyocera ECOSYS M4125idn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera ECOSYS M4125idn and is the answer not in the manual?

Kyocera ECOSYS M4125idn Specifications

General IconGeneral
N-up printing2, 4
Secure printingYes
Print technologyLaser
Duplex printing modeAuto/Manual
Time to first page (black, normal)5.8 s
Print speed (black, normal quality, A3)12 ppm
Print speed (black, normal quality, A4/US Letter)25 ppm
Duplex print speed (black, normal quality, A4/US Letter)22 ppm
Copier resize25 - 400 %
Duplex copying modeAuto
Maximum copy resolution600 x 600 DPI
Maximum number of copies999 copies
Time to first copy (black, normal)7 s
Copy speed (black, normal quality, A3)12 cpm
Copy speed (black, normal quality, A4)25 cpm
Scan toE-mail, FTP, SMB, USB
Scan driversTWAIN, WIA
Scanner typeFlatbed & ADF scanner
Grayscale levels256
Maximum scan area297 x 420 mm
Scan speed (black)50 ppm
Image formats supportedJPG, MMR, TIF
Document formats supportedPDF, XPS
FaxingNo
Fax memory700 pages
Modem speed33.6 Kbit/s
Fax coding methodsJBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)400 x 400 DPI
Fax transmission speed33.6 sec/page
Printing colorsBlack
Duplex functionsCopy, Fax, Print, Scan
Maximum duty cycle15000 pages per month
Recommended duty cycle4000 - 8000 pages per month
Replacement cartridgesTK-6115 (15.000 pagina's)
Number of print cartridges1
Page description languagesMicrosoft XPS, OpenXPS, PCL 5e, PCL 6, PCL XL, PostScript 3
Processor cores2
Processor familyARM Cortex-A9
Card reader integrated-
Compatible memory cardsSD
Maximum internal memory3000 MB
Sound power level (standby)34 dB
Sound pressure level (copying)49 dB
Standard interfacesEthernet, USB 2.0
Optional connectivityEthernet, Wireless LAN
USB 2.0 ports quantity3
Paper input typeCassette, Paper tray
Total input capacity500 sheets
Total output capacity300 sheets
Maximum input capacity1600 sheets
Multi-Purpose tray input capacity100 sheets
Auto document feeder (ADF) input capacity50 sheets
Custom media width98 - 297 mm
Maximum print size297 x 432 mm
Custom media length148 - 432 mm
Media thickness (min)0.11 mm
Paper tray media typesPlain paper
Paper tray media weight60 - 163 g/m²
Non-ISO print media sizesFolio (media size), Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)A3, A4, A5, A6
ISO B-series sizes (B0...B9)B5
Multi-purpose tray media typesLegal, Letter
Maximum ISO A-series paper sizeA3
Multi-Purpose Tray media weight45 - 256 g/m²
Auto Document Feeder (ADF) media weight45 - 160 g/m²
DisplayTFT
Control typeTouch
Product colorBlack, White
Display diagonal4.3 \
Market positioningBusiness
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)0.1 W
Power consumption (ready)65 W
Power consumption (sleep)0.5 W
Power consumption (PowerSave)45 W
Power consumption (average operating)410 W
Energy Star Typical Electricity Consumption (TEC)0.96 kWh/week
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
CertificationTÜV/GS, CE
Cables includedAC
Included cartridge capacity (black)3000 pages
Operating altitude0 - 3500 m
Non-operating altitude0.6 - 15000 m
Storage temperature (T-T)-20 - 40 °C
Operating temperature (T-T)10 - 32.5 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)10 - 80 %
Sustainability certificatesBlue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package width760 mm
Package height911 mm
Package weight72000 g
Harmonized System (HS) code84433100
Weight and Dimensions IconWeight and Dimensions
Width590 mm
Height688 mm
