5-45
Operation on the Machine > Printing from the Handheld Device
Printing from the Handheld Device
This machine supports the print functions and services listed below.
AirPrint
Google Cloud Print
•Mopria
According to the supported OS and application, you can print the job from any handheld device or computer without
installing a printer driver.
Printing by AirPrint
AirPrint is a printing function that is included standard in iOS 4.2 and later products, and Mac OS X 10.7 and later
products.
To use the AirPrint, make sure that the AirPrint setting is enabled in the Command Center RX.
Command Center RX User Guide
Printing by Google Cloud Print
Google Cloud Print is a printing service provided by Google. This service enables a user with a Google account to print
from a machine connected to the Internet.
The machine can be configured in the Command Center RX.
Command Center RX User Guide
Printing by Mopria
Mopria is a standard on printing function included in Android 4.4 or later products. Mopria Print Service needs to be
installed and enabled in advance.
For details on how to use, refer to a Web site of Mopria Alliance.
Printing with Wi-Fi Direct
Wi-Fi Direct is a wireless LAN standard that Wi-Fi Alliance has been established. This is one of the functions of the
wireless LAN, without a wireless LAN access point or wireless LAN router, between devices can communicate directly
on a peer to peer basis.
The printing procedure by the Wi-Fi Direct is the same as that from the normal handheld devices.
When you use a printer name or Bonjour name on the port settings of the printer property, you can print the job by
specifying the name at Wi-Fi Direct connection.
When you use an Time Zone for the port, specify the Time Zone of this machine.
NOTE
A Google account is necessary to use Google Cloud Print. Obtain a Google account if you do not have one.
It is also necessary to register the machine with the Google Cloud Print service in advance. The machine can
be registered from a PC connected to the same network.

Table of Contents

Other manuals for Kyocera ECOSYS M4125idn

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Kyocera ECOSYS M4125idn and is the answer not in the manual?

Kyocera ECOSYS M4125idn Specifications

General IconGeneral
N-up printing2, 4
Secure printingYes
Print technologyLaser
Duplex printing modeAuto/Manual
Time to first page (black, normal)5.8 s
Print speed (black, normal quality, A3)12 ppm
Print speed (black, normal quality, A4/US Letter)25 ppm
Duplex print speed (black, normal quality, A4/US Letter)22 ppm
Copier resize25 - 400 %
Duplex copying modeAuto
Maximum copy resolution600 x 600 DPI
Maximum number of copies999 copies
Time to first copy (black, normal)7 s
Copy speed (black, normal quality, A3)12 cpm
Copy speed (black, normal quality, A4)25 cpm
Scan toE-mail, FTP, SMB, USB
Scan driversTWAIN, WIA
Scanner typeFlatbed & ADF scanner
Grayscale levels256
Maximum scan area297 x 420 mm
Scan speed (black)50 ppm
Image formats supportedJPG, MMR, TIF
Document formats supportedPDF, XPS
FaxingNo
Fax memory700 pages
Modem speed33.6 Kbit/s
Fax coding methodsJBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)400 x 400 DPI
Fax transmission speed33.6 sec/page
Printing colorsBlack
Duplex functionsCopy, Fax, Print, Scan
Maximum duty cycle15000 pages per month
Recommended duty cycle4000 - 8000 pages per month
Replacement cartridgesTK-6115 (15.000 pagina's)
Number of print cartridges1
Page description languagesMicrosoft XPS, OpenXPS, PCL 5e, PCL 6, PCL XL, PostScript 3
Processor cores2
Processor familyARM Cortex-A9
Card reader integrated-
Compatible memory cardsSD
Maximum internal memory3000 MB
Sound power level (standby)34 dB
Sound pressure level (copying)49 dB
Standard interfacesEthernet, USB 2.0
Optional connectivityEthernet, Wireless LAN
USB 2.0 ports quantity3
Paper input typeCassette, Paper tray
Total input capacity500 sheets
Total output capacity300 sheets
Maximum input capacity1600 sheets
Multi-Purpose tray input capacity100 sheets
Auto document feeder (ADF) input capacity50 sheets
Custom media width98 - 297 mm
Maximum print size297 x 432 mm
Custom media length148 - 432 mm
Media thickness (min)0.11 mm
Paper tray media typesPlain paper
Paper tray media weight60 - 163 g/m²
Non-ISO print media sizesFolio (media size), Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)A3, A4, A5, A6
ISO B-series sizes (B0...B9)B5
Multi-purpose tray media typesLegal, Letter
Maximum ISO A-series paper sizeA3
Multi-Purpose Tray media weight45 - 256 g/m²
Auto Document Feeder (ADF) media weight45 - 160 g/m²
DisplayTFT
Control typeTouch
Product colorBlack, White
Display diagonal4.3 \
Market positioningBusiness
Cabling technology10/100/1000Base-T(X)
Ethernet LAN data rates10, 100, 1000 Mbit/s
Mobile printing technologiesApple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (off)0.1 W
Power consumption (ready)65 W
Power consumption (sleep)0.5 W
Power consumption (PowerSave)45 W
Power consumption (average operating)410 W
Energy Star Typical Electricity Consumption (TEC)0.96 kWh/week
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
CertificationTÜV/GS, CE
Cables includedAC
Included cartridge capacity (black)3000 pages
Operating altitude0 - 3500 m
Non-operating altitude0.6 - 15000 m
Storage temperature (T-T)-20 - 40 °C
Operating temperature (T-T)10 - 32.5 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)10 - 80 %
Sustainability certificatesBlue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package width760 mm
Package height911 mm
Package weight72000 g
Harmonized System (HS) code84433100
Weight and Dimensions IconWeight and Dimensions
Width590 mm
Height688 mm
