Kyocera ECOSYS M4125idn User Manual

xxxiv
> Menu Map
Printer
System Menu Settings Description Reference
Page
Printer Emulation Select the emulation for operating this machine by commands
oriented to other types of printers.
8-29
EcoPrint EcoPrint saves toner when printing. 8-29
Override A4/Letter Select whether to treat A4 size and Letter, which are similar in
size, as the same size when printing.
8-29
Duplex Printing Select binding orientation for duplex mode. 8-29
Copies Set the default number of copies, from 1 to 999. 8-29
Print Orientation Set the default orientation, [Portrait] or [Landscape]. 8-29
Wide A4 Turn this to on to increase the maximum number of characters
that can be printed in a line for an A4 page (80 characters at
10 pitch) and Letter size page (80 characters at 10 pitch).
8-29
Form Feed Timeout When the preset timeout passes, the machine automatically
prints paper. You can specify the timeout time.
8-29
LF Action Set the line feed action when the machine receives the line
feed code (character code 0AH).
8-29
CR Action Set the character return action when the machine receives the
character return code (character code 0DH).
8-29
Job name Set whether the job name set in the printer driver is displayed. 8-30
User Name Set whether the user name set in the printer driver is
displayed.
8-30
MP Tray Priority If paper is set in the MP Tray then it is possible for priority to
be given to that MP tray in the paper feed.
8-30
Paper Feed Mode While printing from the computer, select how to feed paper
when the paper source and type are specified.
8-30
Auto Cassette Change Select the following actions when the paper runs out in the
paper source while printing.
8-30
Resolution Set the resolution used for printing. 8-30
KIR Select the default KIR (smoothing) setting. 8-31
Printing Job Terminator Job terminator conditions can be specified in cases where
print jobs are not processed to the end due to the usage
environment or some other reason.
8-31

Kyocera ECOSYS M4125idn Specifications

General

N-up printing	2, 4
Secure printing	Yes
Print technology	Laser
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	5.8 s
Print speed (black, normal quality, A3)	12 ppm
Print speed (black, normal quality, A4/US Letter)	25 ppm
Duplex print speed (black, normal quality, A4/US Letter)	22 ppm
Copier resize	25 - 400 %
Duplex copying mode	Auto
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
Time to first copy (black, normal)	7 s
Copy speed (black, normal quality, A3)	12 cpm
Copy speed (black, normal quality, A4)	25 cpm
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Maximum scan area	297 x 420 mm
Scan speed (black)	50 ppm
Image formats supported	JPG, MMR, TIF
Document formats supported	PDF, XPS
Faxing	No
Fax memory	700 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	33.6 sec/page
Printing colors	Black
Duplex functions	Copy, Fax, Print, Scan
Maximum duty cycle	15000 pages per month
Recommended duty cycle	4000 - 8000 pages per month
Replacement cartridges	TK-6115 (15.000 pagina's)
Number of print cartridges	1
Page description languages	Microsoft XPS, OpenXPS, PCL 5e, PCL 6, PCL XL, PostScript 3
Processor cores	2
Processor family	ARM Cortex-A9
Card reader integrated	-
Compatible memory cards	SD
Maximum internal memory	3000 MB
Sound power level (standby)	34 dB
Sound pressure level (copying)	49 dB
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Ethernet, Wireless LAN
USB 2.0 ports quantity	3
Paper input type	Cassette, Paper tray
Total input capacity	500 sheets
Total output capacity	300 sheets
Maximum input capacity	1600 sheets
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	50 sheets
Custom media width	98 - 297 mm
Maximum print size	297 x 432 mm
Custom media length	148 - 432 mm
Media thickness (min)	0.11 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Folio (media size), Ledger (media size), Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A3, A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Multi-purpose tray media types	Legal, Letter
Maximum ISO A-series paper size	A3
Multi-Purpose Tray media weight	45 - 256 g/m²
Auto Document Feeder (ADF) media weight	45 - 160 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (ready)	65 W
Power consumption (sleep)	0.5 W
Power consumption (PowerSave)	45 W
Power consumption (average operating)	410 W
Energy Star Typical Electricity Consumption (TEC)	0.96 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TÜV/GS, CE
Cables included	AC
Included cartridge capacity (black)	3000 pages
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package width	760 mm
Package height	911 mm
Package weight	72000 g
Harmonized System (HS) code	84433100

Weight and Dimensions

Width	590 mm
Height	688 mm
