9-21
User Authentication and Accounting (User Login, Job Accounting) > Setting User Login Administration
1
Display the screen.
1 [System Menu / Counter]key > [User Login/Job Accounting]
2 [User Login Settings] > [Obtain NW User Property] > [On]
2
Configure the settings.
Add information on each item > [OK]
*1 If your Windows Active Directory is being used, the server name may be the same as the server name entered for network
authentication.
*2 If Windows Active Directory is being used, this normally uses the attribute's displayName.
*3 Name 2 can be left out. When you assign displayName in "Name 1" and department in "Name 2", and if the value of dis-
playName is "Mike Smith" and the value of department is "Sales" in Active Directory of Windows, the user name appears
as "Mike Smith Sales".
*4 If using Windows Active Directory is being used, the attribute's mail is normally used.
*5 Appears when the server type is set to "Kerberos" in "Network Authentication".
If the user authentication screen appears, enter your login user name and login password and select [Login].
For this, you need to log in with administrator privileges.
The factory default login user name and login password are set as shown below.
Login User Name
ECOSYS M4125idn:2500, ECOSYS M4132idn:3200
Login Password
ECOSYS M4125idn:2500, ECOSYS M4132idn:3200
Item Description
Server Name
*1
Enter the LDAP server name or the IP address (up to 64 characters). If a server name is not
entered, user information will be acquired from the server set for Network Authentication.
Port Port number for LDAP server. The default port number is 389.
Name 1
*2
Enter the LDAP Attribute to obtain the user name to be displayed from the LDAP server (up to
32 characters).
Name 2
*3
E-mail Address
*4
Enter the LDAP Attribute to obtain the E-mail address from the LDAP server (up to 128
characters).
Authentication Type
*5
Set the authentication method. Select [Simple] or [SASL]. After changing the setting, restart
the system or turn the power off and then on.
Search Timeout Set the amount of time to wait before time-out in seconds (from 5 to 255 seconds).
LDAP Security (User
Property)
Select the type of encryption according to the type of security employed by the LDAP server.
The value is [Off], [SSL/TLS] or [STARTTLS].
To Next Page
