2RV/2RW/2RX/2RY/3RA
4-20
11. Pull out the fuser unit (a) while holding
the both ends of it.
12. Check or replace the fuser unit (a), and
then reattach the parts which are
detached in the original position.
Attention:
When detaching and reattaching, pay attention
not to burn by touching the hot section.
Figure 4-30
a
To Next Page
