2RV/2RW/2RX/2RY/3RA-1
4-23
4. Release two hooks (b) at the rear side
of the left cover (a).
5. While tilting the left cover (a), detach it
in the direction of the arrow.
Figure 4-35
(1-4)Detaching and reattaching the right cover
Procedures
1. Twist three hooks (b) at the rear side of
the right cover (a) to detach it.
2. Release two hooks by using a flat-head
screwdriver (c).
Figure 4-36
b
a
a
b
c
To Next Page
