Kyocera ECOSYS P2040dn Service Manual

2RV/2RW/2RX/2RY/3RA-3
7-8
(1-10) Blurred image
(1-11) Blurred characters
(1-12) Color shift in the main scanning direction
(1-13) Color shift in the sub scanning direction
Step Check description Assumed cause Measures Reference
1 Replacing the paper The paper is damp. Replace with the new dry
paper.
2 Checking the paper stor-
age place
Paper is stored in the high
humidity environment.
Ask users to store paper in a
dry place. Put the dry paper
into the plastic bag and seal
the bag to prevent moisture
from getting in.
Step Check description Assumed cause Measures Reference
1 Replacing the paper Unspecified papers are
used.
Replace with the paper within
the specification.
2 Changing the settings The media type is not
properly set.
Select the proper media type
in the system menu.
3 Applying the grease The main motor drive is
not transmitted smoothly.
Apply grease to the drive
gears.
4 Replacing the conveying
guide
The conveying guide is
deformed.
Replace the conveying guide.
5 Replacing the fuser unit The fuser front guide is
deformed or the fuser
pressure is uneven.
Replace the fuser unit.
Step Check description Assumed cause Measures Reference
1 Replacing the LSU The LSU is faulty. Replace the LSU.
Step Check description Assumed cause Measures Reference
1 Checking the main/engine
PWB
The connector and FFC
are not connected properly
or the wire, FFC or PWB is
faulty.
Reconnect the connector and
FFC that are connected to
the main/engine PWB. If the
wire is pinched or scratched,
or the FFC terminal is peel or
deformed, correct or replace
it. If not repaired, replace the
main/engine PWB.

Kyocera ECOSYS P2040dn Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6.4 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Duplex print speed (black, normal quality, A4/US Letter)	20 ppm
Printing colors	Black
Maximum duty cycle	50000 pages per month
Replacement cartridges	TK-1160 (7.200 pagina's)
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PCL XL, XPS
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.1 W
Power consumption (ready)	8 W
Power consumption (printing)	620 W
Power consumption (PowerSave)	0.8 W
Energy Star Typical Electricity Consumption (TEC)	1.6 kWh/week
Internal memory	256 MB
Processor frequency	800 MHz
Compatible memory cards	SD, SDHC
Sound pressure level (printing)	48.8 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Market positioning	Home & office
Display number of lines	2 lines
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Maximum input capacity	850 sheets
Maximum number of input trays	3
Multi-Purpose tray input capacity	100 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Plain paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi standards	Not supported
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Kyocera Mobile Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificates	Blue Angel, ENERGY STAR
Package depth	516 mm
Package width	500 mm
Package height	400 mm
Package weight	18000 g
Cables included	AC
Included cartridge capacity (black)	3600 pages
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	272 mm
Weight	14000 g
